A3-B downlight monorail in-line AOI_.pdf - 第4页
platform marble platform X/Y platform driver Screw and AC ser vo motor drive, PCB/FPC fixed, Camera moves in XY dir ection power supply AC220V 50/60Hz less than 1.5KV A air pressure 0.4-0.8Mpa Operating environment tempe…
Resolution
Visual Range
Speed
Standard configuration:
15μm/Pixel FOV: 36mmx30mm Detection speed <200ms/FOV
option:
20μm/Pixel FOV: 48mmx40mm Detection speed <200ms/FOV
option:
25μm/Pixel FOV: 60mmx50mm Detection speed <200ms/FOV
option:
10μm/ Pixel FOV: 24mmx20mm detection speed <200ms/FOV
Standard c
onfiguratio
n:
15μm/Pixel
FOV: 60mm
x45mm Det
ection spee
d <200ms/F
OV
option:
10μm/Pixel
FOV: 40mm
x30mm Det
ection spee
d <200ms/F
OV
option:
7μm/Pixel F
OV: 28mmx
21mm Dete
ction speed
<200ms/FO
V
option:
3.45μm /Pix
el FOV: 13.8
0mmx10.35
mm detecti
on speed <
200ms/FOV
light source High-brightness RRGB coaxial ring-shaped tower LED light source (color light)
Conveyor system
Bottom-up fixing, automatic compensation for PCB/FPC bending deformation, automatic in and out
of boards, automatic width adjustment of flat belts
Conveyor height above ground 890 to 980 mm
Conveyor flow direction Can be set left to right or right to left
platform marble platform
X/Y platform driver Screw and AC servo motor drive, PCB/FPC fixed, Camera moves in XY direction
power supply AC220V 50/60Hz less than 1.5KVA
air pressure 0.4-0.8Mpa
Operating environment
temperature and humidity
10-35℃ 35-80% RH (no condensation)
Functional part
Test content
Component detection: missing parts, reversal, offset, component bent legs, wrong parts, tin stain,
glue overflow, damaged parts
Welding detection: too much tin, too little tin, side standing, tombstone, tin bridge, empty soldering,
tin beads , raised legs, soldering after wave soldering (including plug-ins)
PCB/FPC size range 50*50mm (min) ~ 450*600mm (max)
PCB/FPC thickness range 0.3 to 5mm
PCB/FPC clamping system edge
clearance
TOP: 3.5mm Bottom: 3.5mm
Greater PCBA/FPCA weight 3KG (overweight can be customized)
PCB/FPC curvature <5mm or 2% of PCB diagonal length
PCB/FPC upper and lower clear
height
PCB/FPC top side: 120mm PCB/FPC bottom side: 40mm
smallest component 3.45μm: 01005chip & 0.3 pitch IC
Barcode function Automatic barcode recognition (1D or 2D code)
Special features
Supports automatic program retrieval, multi-board multi-program detection function, front and
back program detection function; can check 0-359° rotating parts (unit is 1°).
remote control
Realize remote operation through TCP/IP network, view, start or stop machine operation, modify
programs and other operations anytime and anywhere
Server mode Using a central server, several AOI data can be centrally and uniformly managed.
SPC statistics
Record test data throughout the process and perform statistics and analysis. Production status and
quality analysis can be viewed in any area, and file formats such as Excel and txt can be output.
