YSM20-FM_KLW-M745H-00_FM_MAINTE.PARTS SET_20171226_.pdf.pdf
1 2 YSM20-FM : KLW-M745H-00 FM MAINTE.PARTS SET 6 4 4 3 5 3 5 6 CS1508002J/E-000 No. Part No. Part Name Q'ty Remarks 1 2 3 4 5 6 7 8 KLW-M8527-00 KLW-M715B-00 KV7-M8171-00 90990-01J057 KV7-M81D4-00 90440-10J008 9099…
1
2
YSM20-FM : KLW-M745H-00 FM MAINTE.PARTS SET
6
4
4
3
5
3
5
6
CS1508002J/E-000
No. Part No. Part Name Q'ty Remarks
1
2
3
4
5
6
7
8
KLW-M8527-00
KLW-M715B-00
KV7-M8171-00
90990-01J057
KV7-M81D4-00
90440-10J008
90990-17J081
90990-17J082
FILTER
GASKET
PLATE SPRING
BOLT,HEX.SOCKET HEAD
ROLLER
CIRCLIP
O-RING
O-RING
5
5
20
10
10
10
5
5
7
NOZZLE 304A/315A ASSY.
NOZZLE 307A/318A ASSY.
8
YAMAHA MOTOR CO,.LTD.
