12-segm. collect+place head compl./DLM4
Page 19 / 21 24.11.2021
Pos. Item no. Description Part marking
164 00336426S01 SHEET METAL COVER F. REAR PART
DLM1/12
SPARE PART
165 00336427S01 ANTI-GLARE SHIELD FRONT
PANEL/DLM1
SPARE PART
167 03001806-01 COVER IN FRONT COM. / DLM SPARE PART
00066176-01 PACKING FOR PLACEMENT HEAD
6/12
03006191-01 TRANSPORT TRAY F.
COLLECT&PLACE HEAD
CONSUMABLE
00066172-02 TRANSPORT PROT. F. PLACEMENT
HEAD 6/12
Consumable
00066173-03 INNER BOX F. PLACEMENT HEAD
6/12
Consumable
00066025-01 EGB-BAG 500*600*0,08MM BLACK
0157
Spare Part
00066174-01 PLUG IN WITH HANDLE
00066081-02 PLUG IN 1 UNIVERSAL PACKING
00066080-01 FOLDING CARTON SMD
-PLACEMENT HEAD 395*395*410
MM
00322626-04 SEAL FOR
PACKAGE:ORIGINALVERPACKT,D=6
5
168 00350588S04 12ER- SLEEVE WITH BALL FIXING
COMP.
SPARE PART
169 03037984-03 VAKUUM PLATE COMPL. DLM / R-
LIGHTBEIGE
WEAR PART
170 00322602-06 NOZZLE TYPE 704/904/3004 CPL. /
CERAMIC
WEAR PART
171 03014449S05 BE-CAMERA C+P (TYP28) 18X18
DIGITAL RK
SPARE PART
03015967-02 PLATINE/VISION LED-TREIBER
SST28
03062799S02 ROUND CABLE SET: C+P-CAM.
(TYPE28,29,38)
*
03081918-01 UPGRADE KIT DLM4-12 FOR DX1/2
172 03082158-01 ADAPTER PLATE CPLT. DLM4-DX1/2
03082319-01 ADAPTER PLATE DLM4-DX1/2
03001387-01 CABLEHOLDER
03082421-01 CABLEHOLDER 2
173 03072187-01 PLATE / CPP
12-segm. collect+place head compl./DLM4
Page 20 / 21 24.11.2021
Pos. Item no. Description Part marking
03082623-01 LAPPED PIN
03082443-01 RETAINING ELEMENT DLM DX
174 03001830-01 CABLE SUPPORT SPARE PART
03082426-01 FLAT CABLE HOLDER
175 03081920-01 HEAD ADAPTER HCU FOR DLM4 -
DX1/2
176 03084408S03 PCB BASIC ADAPTER DLM XE SPARE PART
177 03054884-03 HCU CPL. Spare Part
03084789-01 FLAT RIBBON CABLE SET
DLM4-DX1/2
SPARE PART
03023819-02 ASSEMBLYKIT BE.KAMERA SST28/29
DLM2
03022736-02 CABLEMOUNTING COMPLETE
03001830-01 CABLE SUPPORT SPARE PART
03022640-02 CABLEMOUNTING
03014437-01 CABLEHOLDER/ C+P SPARE PART
03081921-01 PIPING DLM - DX1/2
03051799-01 L-TYPE QUICK-RELEASE FASTENER
QSL-8
03052399-01 RECEPTACLE REDUCING QSH-12-8
00330249-01 BLANKING PLUG QSC-4H STANDARD PARTS
00337891-01 PLUG QSC-6H
03006728S01 PVC CAP TYP D DI8,0 H 15 10X SPARE PART
03014616S01 HOSE/EXHAUST AIR C+P20 CONSUMABLE
03006727S01 SILICON HOSE DI 8 DA 12
EL.CONDUCTIVE
SPARE PART
03083785-01 TUBE PLACEMENT CIRCLE DLM-
DX1/2
03055411S01 PLASTIC TUBE PUN-CM-6-SW
ANTISTAT. (1M)
SPARE PART
03083786-01 TUBE HOLDING CIRCLE DLM-DX1/2
03083787-01 PLASTIC TUBE PUN-CM-8-SW
ANTISTAT.
03048638-02 BOX SPARE PART
03084472-01 COVER PLATE DLM-DX1/2
03017800-01 BRACKET
03084438-01 PLATE DX1/2
03083803-02 BUFFER EXTENSION DLM-DX1/2
12-segm. collect+place head compl./DLM4
Page 21 / 21 24.11.2021
Pos. Item no. Description Part marking
03084499-01 AIRGUIDE SHEET DX1/2
03086331-01 CAMERA LONG CABLE KIT DLM
DX1/2
03083678-01 HOTLINK CAMERA ADAPTER COMPL.
03086332-01 CAMERA CABLE EXTENSION DLM
DX1/2
*
00308458-01 CABLE TIES B=2.5MM, L=102MM
PANDUIT
STANDARD PARTS
03075147S01 CABLE CUFF SPARE PART
