Packing List
The following items are included according to purchased station reference:
Preheater Set
for PCBs up to 13 x 13 cm / 5 x 5 in ................................... 1 unit
Ref. PHSE-9B (100 V)
Ref. PHSE-1B (120 V)
Ref. PHSE-2B (230 V)
Articulated Hand Rest
for PHSEK Preheater Set ............................................................ 1 unit
Ref. RHS-A
Multiaxis Rotative Support
for PCBs up to 13 x 13 cm / 5 x 5 in ......................................... 1 unit
Ref. PSS-A
Installation
PHSE
Preheater Unit
ACE
Console
Power Cord
Included in PHSE Preheater
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
Exploded View
PHSE
Preheater Unit
PSS
Multiaxis Rotative Support for PCB
ACE
Console
RHS
Articulated Hand Rest
for PHSEK Preheater Set
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must be collected and returned to an authorized
recycling facility.
Warranty
Information regarding the warranty of each
product can be found on the final page of its
instruction manual.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
0035069 - 080125
Specifications
RBSM
Multiaxis Rework Bench for PCBs up to 13 x 13 cm / 5 x 5 in
Ref. RBSM-9A
Ref. RBSM-1A
Ref. RBSM-2A
- Package Dimensions / Weight: 620 x 385 x 395 mm / 15.50 kg
(L x H x W) 24.41 x 15.16 x 15.55 in / 34.17 lb
Complies with CE standards.
ESD safe.
