Ref No. Remarks R 1 Q't y 㪈㪏 㪍ㅪ䊐䉞䊷䉻タㇱ㪑䊐䉞䊷䉻䉦䊋䊷ㇱ㩿㪚㪤㪍㪇㪉㪀 Feeder set six reams:Feeder cover(CM602) 䍐䍵䍛䍢 㪥㫆㪅 Part No. ຠ䇭䇭ฬ ຠ⇟ ᢙ㊂ R 2 䊌䊷䉿䊥䉴䊃 Kit No . 䉨䉾䊃ຠ ⇟ Kit Name 䉨䉾䊃ฬ⒓ N610027829AA Part N ame 䇭䇭䇭⠨ 䍜䍖䍚䍌䍻㪥㫆㪅 PARTS LIS…
㪈㪏
㪍ㅪ䊐䉞䊷䉻タㇱ㪑䊐䉞䊷䉻䉦䊋䊷ㇱ㩿㪚㪤㪍㪇㪉㪀
Feeder set six reams:Feeder cover(CM602)
䊌䊷䉿䊧䉟䉝䉡䊃
Kit No.
䉨䉾䊃
ຠ⇟
Kit Name
䉨䉾䊃ฬ⒓
N610027829AA
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
S59
-0##
Ref
No.
Remarks
R
1
Q't
y
㪈㪏
㪍ㅪ䊐䉞䊷䉻タㇱ㪑䊐䉞䊷䉻䉦䊋䊷ㇱ㩿㪚㪤㪍㪇㪉㪀
Feeder set six reams:Feeder cover(CM602)
䍐䍵䍛䍢
㪥㫆㪅
Part No.
ຠ䇭䇭ฬຠ⇟ ᢙ㊂
R
2
䊌䊷䉿䊥䉴䊃
Kit No.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610027829AA
Part Name
䇭䇭䇭⠨
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LIST
Section No.
R
3
COVER
1
1 N210079536AA
COVER
1
2 N210041577AC
COVER
1
3 N210041578AA
COVER
1
4 N210041455AC
COVER
1
5 N210041579AB
COVER
1
6 N210041576AA
SCREW
12
7 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
SCREW
6
8 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
COLLAR
2
9 N210071617AA
BRACKET
1
10 N210079537AA
DOG
1
11 N210079538AA
MAGNET
1
12 KXF0CS8AA00 C-54-2-black
BRACKET
1
13 N210118913AA
SCREW
2
14 N510018233AA
Cross recessed Truss head machine screw M3X10-4.8 A2S (Trivalent)
SCREW
2
15 N510018266AA
Cross recessed Truss head machine screw M4X16-4.8 A2S (Trivalent)
BOLT
2
16 N510017337AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent)
WASHER
4
17 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
NUT
2
18 N510017849AA
Hexagon nut Type-1 Best class M3-6H-4T A2J (Trivalent)
