S3088 DT | 3D-SPI System Variant – Technical Specifications

Side view

S3088 DT | 3D-SPI system variant

Inspection scope

3D SPI

Inspection of solder paste possible deposits, stencil printing and dispensing

technology (up to pad sizes for 01005 components) as well as sinter paste;

inspection of component presence, surface, height, print displacement

(X/Y offset), paste smearing and, as options: shape, coplanarity, open area

analysis, OCR and DCM

Camera technology

3D camera technology

Measuring procedure Structured light projection

Z-resolution 0.1µm

Z-measurement area 4mm (0.2")

Angled view cameras

Number of megapixel cameras 4

Orthogonal camera

Resolution Standard: 20μm, high resolution: 10μm

Field of view size 58.2mm x 58.2mm (2.3" x 2.3")

Software

User interface Viscom vVision/EasyPro

Statistical process control Viscom SPC/vSPC, open interface (optional)

Verification station Viscom vVerify/HARAN

Remote diagnosis Viscom SRC (software remote control) (optional)

Programming station Viscom PST34 (optional)

System computer

Operating system Windows®

Processor Intel® Core™ i7

PCB handling

Transport concept Dual-track transport

Printed circuit board size (L x W) 450mm x 350mm, minimum width 70mm

Transfer height 900 - 950 mm ± 20 mm (35.4" - 37.4" ± 0.8")

Width adjustment Automatic*

PCB clamping Pneumatic

Upper transport clearance (max.) 50mm (2")

Lower transport clearance 40mm* (1.6")

Other system data

Positioning unit Synchronous linear motors

Interfaces SMEMA (standard), IPC Hermes standard, other interfaces on request

Power requirements 400 V (other voltages on request), 3P/N/PE, 8 A

Compressed air 10 bar max. (4 - 6bar working pressure)

System dimensions 1094mm x 1565mm x 1692mm (43.1" x 61.6" x 66.6") (W x H x D)

Weight 1400kg (3086 lbs)

* Various width adjustments and transport clearances on request.
