Control unit F5
Page 9 / 11 19.11.2021
Pos. Item no. Description Part marking
CONTROL UNIT
30 00321691-02 CABLE: KEYBOARD - ADAPTER SPARE
31 00321548-02 CABLE: CONTROL UNIT-
CONVERSION BOARD
Spare Part
32 00322095-02 CABLE: TERMINAL BOARD -
CONTROL UNIT
33 00321439-03 CONTROL UNIT - CONVERSION
BOARD PORTAL
00321581-01 GROUND STRAND (TERMINAL
BOARD - CONTROL)
35 00321898-03 CABLE: CONTROL UNIT -
CONVERSION BOARD P
36 00322365-02 CABLE: CONTROL UNIT-
ILLUMINATION CONTROL
37 00321585-04 CABLE CAN-BUS GANTRY 1
00323948-01 CAN-BUS CABLE:CONTROL UNIT-
IC.LIGHT UNIT
00321587-03 CABLE: CRASH-SIGNAL (TERMINAL
BD CONV.)
00321787-02 CABLE: VOLTAGE STAR-MOTOR
PORTAL 1
41 00321497-02 CABLE: I/O-TERMINAL BOARD(KSP-
P218)
42 00321498-02 CABLE: I/O-TERMINAL BOARD(KSP-
P218)
43 00321499-02 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
44 00321500-03 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
45 00321501-04 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
46 00321502-03 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
47 00321503-02 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
48 00321504-03 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
49 00321778-03 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
50 00321779-03 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
51 00321780-03 CABLE: I/O-TERMINAL BOARD (KSP-
Control unit F5
Page 10 / 11 19.11.2021
Pos. Item no. Description Part marking
P218)
52 00321508-03 CABLE: I/O-TERMINAL BOARD (KSP-
P218)
53 00321890-02 CABLE: CONTROL UNIT - SERVO
UNIT
54 00321891-01 CABLE: CONTROL UNIT - SERVO
UNIT
55 00321892-02 CABLE: CONTROL UNIT - SERVO
UNIT
56 00321893-03 CABLE: CONTROL UNIT - SERVO
UNIT
57 00321894-03 CABLE: CONTROL UNIT - SERVO
UNIT
58 00321895-02 CABLE: CONTROL UNIT - SERVO
UNIT
59 00321896-02 CABLE: CONTROL UNIT - SERVO
UNIT
60 00321536-02 CABLE: TRACK (Y-AXIS)
61 00321538-02 CABLE: TRACK (X-AXIS)
62 00321540-02 CABLE: TRACK SIGNALS DR-AXIS
SP/IC1-HEAD
63 00321542-02 CABLE: TRACK SIGNALS Z-AXIS
SP/IC1-HEAD
64 00321546-03 CABLE: TRACK SIGNALS DP1-AXIS
65 00321899-01 CABLE: TRACK SIGNALS Z-AXIS IC2
66 00321900-02 CABLE: TRACK SIGNALS DR-AXIS
IC2
67 00370792-01 CABLE HS50: TP-LAN-BUS MC-LINE
COMPUTER
68 00321798-01 CABLE-VGA: MULTIPLEXER-
CONTROL UNIT
69 00306068-06 CABLE: KAMERA COMPONENT
VISION
SPARE PART
70 00322277-01 CABLE COPLANARITY SIPLACE 80F SPARE
00306067-03 CABLE COMP. MODULE Spare Part
00321789-02 CABLE: VOLTAGE ILLUMINATION
PORTAL 1
00336795-02 CABLE: COPLANAR MODULE -
TERMINAL STRIP
00345352-01 CABLE TREE COPLANAR MODULE
F5-HM
Control unit F5
Page 11 / 11 19.11.2021
Pos. Item no. Description Part marking
00116063-01 GEM INTERFACE SI80 S-20/F4/F5
405.XX/M44
75 00327321S03 GEM-COMPUTER KSP-M44GEM
76 00343252S03 FLOPPY / WINCHESTER FOR CPU
M44
SPARE PART
77 00324351-01 TCP/IP-CONNECTION KSP COM290
00327933-01 BNC-CABLE 2,5M SPARE
00321869-01 BNC T-ADAPTER (B/S/B)
78 00386353-01 GER_FLOPPY_D353G_`1/1,6/2MB Spare Part
