Consistent ultra-high performance.
The SIPLACE HS features 4 vertical
placement heads that rotate around a
horizontal axis. The revolver heads
work alternately, allowing each PCB
to be populated without interruption.
Because the placement heads are
exceptionally light, the placement rate
of the SIPLACE HS is independent of
the size of the components being placed.
Therefore, whether you are placing
18.7 mm ICs, 0201s, flip chips, µBGAs
or CSPs, the placement rate of the
SIPLACE HS remains constant.
An innovative gantry system with a linear
motor drive enables the SIPLACE HS
to maintain an impressive accuracy:
at 90 µm at 4 sigma with a placement
rate of 50,000 cph. By adding modules,
overall throughput can be increased
to rates of 100,000 cph, 150,000 cph
or higher.
The SIPLACE HS is the powerhouse of the SIPLACE platform. With a place-
ment rate of 50,000 components per hour (cph), the SIPLACE HS is best in
class among very high-speed placement systems - and it achieves this with
a very small footprint of 7 m
2
. SIPLACE HS places components faster – and
thus more profitably – than conventional placement machines.
Very High Speed
for Very High Throughput.
Widest component range.
The SIPLACE HS is capable of high-
volume, high-accuracy placement of
0201s and chip components as well as
flip chips. Such components handling
sets the SIPLACE HS far ahead of the
competition.
SIPLACE HS
Very High Speed Placement System.
The HS 50 combines impressive
placement rates with the ultimate
in accuracy.
Revolver
head
Revolver
head
Stationary
component
feeder banks
PCB transport
Stationary
PCB
162.062_Brochure_HS_engl 20.02.2001 10:48 Uhr Seite 2
Very High Speed
Placement System.
Maximum uptime.
Thanks to several technological
innovations, the SIPLACE HS is
significantly faster and more efficient than
other machines in its class. In addition,
downtime is dramatically reduced.
Short revolver head cycle times
Low ink-dot and fiducial recognition
times
Short placement head travel times
due to linear motor technology
Reduced PCB transport times
New changeover tables allow setup
changeovers in a only 2 minutes
Productivity Lift.
With the SIPLACE Productivity Lift,
the performance of the HS series is
enhanced even further. By dividing the
process of populating PCBs among
several placement machines, the
Productivity Lift provides a useful alter-
native to serial production. This innovative
method of parallel processing gives
you access to individual machines while
the remainder of the line continues
to run and is especially useful when
bringing new products into production.
Plus, with SIPLACE software you can
reconfigure your line in seconds without
moving machines. The Productivity Lift
lets you make optimal use of your line
capacity, further increasing productivity.
SIPLACE HS-50
SIPLACE HS is the only high-speed
system capable of reliably placing
0201c.
On the road to zero-defect
production.
Outstanding design makes the
SIPLACE HS the only very high-speed
system that can reliably place 0201s.
PCBs and component feeders remains
stationary providing maximum pickup
and placement reliability. An extremly
dependable gantry system employs a
direct linear-motor drive, which incures
minimal wear. Among super high-
speed machines, the SIPLACE HS has
the lowest defect rate in the industry.
This means less downtime and
maximum output for your manufactu-
ring process.
