March 2024 1
ASYMTEK Select Coat
®
SL-940 Fluid System Spares List
A range of spare parts are available to support Nordson Electronics Soluons products, keeping them running at
peak performance. Nearly all spare parts are sold as part of a spares kit, with a few excepons.
How to Locate and Order Spare Parts
If you are referring to the User Manual to complete a procedure, you can search for a Kit Part Number or an
individual Part Descripon to idenfy the kit or individual part you need to complete the procedure.
If you have a part number, search the Lookup Part Number column in the tables below to idenfy whether the
part is sold in a kit or as an individual part. You will nd it in the Spares Kit List table if it's sold in a kit. You will
nd it in the Individual Part List table if it's sold as an individual part.
To locate a kit or individual part, do the following:
1. Download this le and open it in a browser such as Google Chrome.
2. Use your browser’s search feature to search for a Kit Part Number, individual Part Descripon, or part
number.
o If the part is sold in a spares kit, refer to the corresponding columns in the Spares Kit List table
for details about the kit. Use the Kit Part Number to order the kit.
o If the part is sold individually, refer to the corresponding column in the Individual Part List table
for details. Use the Lookup Part Number to order the part.
3. To request a quote, do the following:
o Click here.
o Locate your region and click the Email link.
A dra email addressed to the recipient you selected is displayed.
o In the Subject eld, type New Request for Quote.
o In the body of the email, provide the following informaon:
▪ The Kit Part Number(s) for the kit(s) you want to order. And the quanty of each kit.
▪ The Lookup Part Number(s) for the individual part(s) you want to order. And the
quanty of each part.
▪ The Ship To informaon: company name and complete shipping address.
▪ Your name, phone number, and email address.
o Click Send.
ASYMTEK Select Coat® SL-940 Fluid System Spares List
March 2024 2
Spares Kit List
All parts listed in the following table are sold only within kits, not individually. The informaon in the Lookup Part
Number column allows you to locate a part that you previously ordered separately but is now only available as
part of a kit. The Quanty column shows the quanty you will receive for each part in a kit.
Kit Name
Kit Part Number
Part Description
Quantity
Lookup Part Number
FRU,UK, FLUID DUAL IND
ASSY, REG/FILTER, DUAL IND, 940
1
6650232
ASSY, 4X FLD FITTINGS 940
1
6147897
ASSY, 940 FLD CONDUIT, LOADED
1
6650137
FRU,UK,FLUID DUAL SIM
ASSY, REG/FILTER, DUAL SIM, 940
1
6650234
ASSY, 4X FLD FITTINGS 940
1
6147897
ASSY, 940 FLD CONDUIT, LOADED
1
6650137
FRU,UK,FLUID HOSE KIT
HOSE,OPAQUE,SS BRAIDED,4FT,#5
2
7229348
HOSE,OPAQUE,SS BRAIDED,4FT,#6
2
7229349
HOSE,OPAQUE,SS BRAIDED,2FT,#5
2
7229324
HOSE,OPAQUE,SS BRAIDED,3FT,#5
2
7229336
FRU,UK,FLUID SING
ASSY, 940 FLD CONDUIT, LOADED
1
6650137
ASSY, 4X FLD FITTINGS 940
1
6147897
ASSY, REG/FILTER, SINGLE, 940
1
6650231
ASSY, REG/FILTER, SINGLE, 940
HOSE,OPAQUE,SS BRAIDED,3FT,#5
1
7229336
HOSE,OPAQUE,SS BRAIDED,2FT,#5
1
7229324
SCREW,M6X1.0X80MM SHCS,BO
1
7220112
ASSY, REG, PSC, 940
2
6650235
ASSY, FILTER + HOSE, 940
1
6149557
MOUNT,3X FILTER & REGULATOR
1
6142443
SCREW, M6X8, SOCK CAP, SS
2
388098
ASSY, REG/FILTER, DUAL IND, 940
HOSE,OPAQUE,SS BRAIDED,3FT,#5
2
7229336
HOSE,OPAQUE,SS BRAIDED,2FT,#5
2
7229324
SCREW,M6X1.0X80MM SHCS,BO
4
7220112
ASSY, REG, PSC, 940
2
6650235
ASSY, FILTER + HOSE, 940
2
6149557
MOUNT,3X FILTER & REGULATOR
1
6142443
SCREW, M6X8, SOCK CAP, SS
4
388098
ASSY, REG/FILTER, DUAL SIM, 940
HOSE,OPAQUE,SS BRAIDED,3FT,#5
2
7229336
HOSE,OPAQUE,SS BRAIDED,2FT,#5
2
7229324
SCREW,M6X1.0X80MM SHCS,BO
2
7220112
FTG,RUN TEE,SWVL,1/2-20JIC
1
7212393
ASSY, REG, PSC, 940
2
6650235
ASSY, FILTER + HOSE, 940
1
6149557
MOUNT,3X FILTER & REGULATOR
1
6142443
SCREW, M6X8, SOCK CAP, SS
4
388098
ASSY, 4X FLD FITTINGS 940
BRKT,BULKHEAD,QUAD,94X
1
7223144
NUT, 1/2-20 HEX
4
7216732
CONN,BLKHD,37D,1/4NPT,SS
4
972516
CONN,MALE,1/4T,X1/4NPT,DELRIN
4
971232
ASSY, 940 FLD CONDUIT, LOADED
TAPE, WIRE MARKERS, Y
1
7275609
TAPE, WIRE MARKERS, X
1
7275608
CONDUIT,TUBING,21MM,EX-FLEX
3
7215969
TUBING,PTFE,1/4X3/16,RED
52
6126521
TAPE, WIRE MARKERS, #3
1
6105120
TAPE, WIRE MARKERS, #2
1
6105119
ASYMTEK Select Coat® SL-940 Fluid System Spares List
March 2024 3
TAPE, WIRE MARKERS, #1
1
6105118
TAPE, WIRE MARKERS, #4
1
6105121
Individual Part List
The following items are sold individually.
Part Description
Lookup Part Number
ASSY,HEATER,NH-4,500W,940
7210788
UPGD,PUMP,DIAPHRAGM,3/8" SS
7292148
HOSE,OPAQUE,SS BRAIDED,4FT,#5
7229348
HOSE,OPAQUE,SS BRAIDED,4FT,#6
7229349
HOSE,OPAQUE,SS BRAIDED,2FT,#5
7229324
HOSE,OPAQUE,SS BRAIDED,3FT,#5
7229336
