Innovative concept for highly flexible adhesive application
As more modern PCB designs
require components on both
sides or a mix of THT and SMT
techniques, the need for affixing
components with adhesives
increases steadily. The best
solution for these applications is
the innovative SIPLACE Glue
Feeder. It can be easily mounted
and dismounted like a component
feeder and dispenses the
adhesive with high precision in
the form of ultra-fine dots from
below directly onto the
components. In short, it delivers
maximum flexibility at low cost.
Precise gluing with the SIPLACE Glue
Feeder
The contrast could not be more severe:
Instead of having to use expensive and
inflexible gluing stations and other complex
procedures, the SIPLACE Glue Feeder gives
electronics manufacturers a flexible way to glue
components with ease and precision.
The SIPLACE Glue Feeder dispenses the
adhesive from below directly onto the
respective component instead of the PCB.
This means that the SIPLACE Glue Feeder is the
ideal solution for applications where only a limited
number of components must be glued.
Another advantage: The easy handling of the
SIPLACE Glue Feeder and the time saved for
setting up, cleaning and programming the SIPLACE
Glue Feeder reduces your costs significantly.
SIPLACE Feeders
SIPLACE Glue Feeder
