1 / 5 機種( M / C TY P E) ユニット( U N I T) 発行日 I P ・Q P 2 モータフィーダ( M O TO R FEE D E R ) 0 0 . 1 0 . 2 7 形式( TY P E) 図番( D W G N o . ) S/ N W 3 2 エンボス( E M B O S S) ( A K D F A 7 1 * * ) K D E‑ 3…
5/5
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W32 エンボス( EMBOSS) ( AKDFA61**) KDE‑ 3200‑ 002362〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
109 ﾜｯｼｬ ｻﾗ WASHER, CONI CAL W1010A 5 M‑ 3‑ L
110 ﾌﾟﾚｰﾄ PLATE KDCC1221 1
111 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 2 M2. 5X6
112 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1040A 5 M3
113 ｽﾍﾟｰｻ SPACER KDFC0421 1
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
1/5
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/N
W32 エンボス( EMBOSS) ( AKDFA71**) KDE‑ 3200‑ 002362〜
番号
品名 図番 個数
No. Dwg. No. QTY
1 ﾎﾝﾀｲ BODY AKDFC6507 1
ﾎﾝﾀｲ BODY KDFC0717 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4443A 1 LF‑ 850ZZ ( NMB)
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4450A 2 LF‑ 1480ZZ( NMB)
ﾋﾟﾝ ﾍｲｺｳ PI N, PARALLEL H2092F 4 A4x10SUS303
2 ｵｻｴ RETAI NER KDFC0410 1
3 ｵｻｴ ﾘｰﾙ RETAI NER, REEL AKDFC6022 1
ｵｻｴ ﾘｰﾙ RETAI NER, REEL KDFC0030 1
ﾌﾟﾚｰﾄ PLATE KDCC0160 1
4 ｼｬﾌﾄ SHAFT AKDFC6037 1
ｼｬﾌﾄ SHAFT KDFC0095 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
5 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR AKDFC6201 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDFC0801 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDFC0811 1
6 ｷﾞﾔ GEAR AKDDC6073 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0551 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0152 1
ｼｬﾌﾄ ﾌﾟｰﾘ SHAFT, PULLEY KDDC0160 1
ｷﾞﾔ GEAR KCBC0401 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
7 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR AKDDC6513 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDDC0733 1
ｽﾍﾟｰｻ SPACER KCBC0160 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ BEARI NG, MI NI ATURE H4569A 1 LFｰ630ZZ ( NMB)
ﾋﾟﾝ ｼﾃﾝ PI N, PI VOT KDDC0210 1
8 ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG AKDCC6072 1
ｶﾗｰ COLLAR KCAC0270 1
ｷﾞﾔ ﾋﾟﾆｵﾝ GEAR, PI NI ON KCAC0470 1
ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG KDCC1400 1
9 ｶﾊﾞｰ COVER AKDCC6122 1
ｶﾊﾞｰ COVER KDCC0571 1
ｶﾊﾞｰ COVER KDCC0581 1
備考
Remarks
Descri pt i on
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
2/5
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/N
W32 エンボス( EMBOSS) ( AKDFA71**) KDE‑ 3200‑ 002362〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
10 ﾘｰﾙ REEL AKDFC6520 1
ﾘｰﾙ REEL KDFC0920 1
ﾏｸﾞﾈｯﾄ MAGNET M1003X 5 丸型ﾈｵｼﾞ磁石φ 5x5
11 ｶﾊﾞｰ COVER KDFC0770 1
12 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE AKDCC6531 1
ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0821 1
ﾋﾟﾝ ｼﾃﾝ PI N, PI VOT KCAC0420 2
13 ｼｬﾌﾄ SHAFT AKDFC6076 1
ｼｬﾌﾄ SHAFT KDFC0074 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0141 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 3 M2. 5x6
ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 3 M2. 5
14 ｶﾞｲﾄﾞﾃｰﾌﾟ GUI DE, TAPE KDFC0041 1
15 ｼｬﾌﾄ SHAFT KDFC0054 2
16 ﾛｰﾗ ROLLER KDFC0061 1
17 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDCC0100 1
18 ﾜｯｼｬ WASHER KDCC0111 3
19 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0124 1
20 ｵｻｴ ﾍﾞｱﾘﾝｸﾞ RETAI NER, BEARI NG KDCC0132 1
21 ﾌﾟﾚｰﾄ PLATE KDCC0742 1
22 ﾌﾟﾚｰﾄ PLATE AKDDC6550 1
ﾌﾟﾚｰﾄ PLATE KDCC1420 1
ﾌﾟﾚｰﾄ PLATE KDCC1340 1
23 ﾚﾊﾞｰ LEVER KDCC0190 1
24 ﾋﾟﾝ PI N KDCC0201 1
25 ｽﾍﾟｰｻ SPACER KDCC0231 4
26 ﾌﾟﾚｰﾄ PLATE KDCC0251 1
27 ﾋﾟﾝ PI N KDFC0103 1
28 ﾛｰﾗ ROLLER KDFC0250 1
29 ﾘｰﾙ REEL KDFC0113 1
30 ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0561 1
31 ﾋﾟﾝ PI N KDCC0321 1
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
