Manufacturing Process Innovation
Model ID
Model No.NM-EJM6E
NPM-D3A
Production Modular
Electronics Assembly System
catalog
2020
機種名
Electric source
Pneumatic source
Dimensions
Mass
Dual-lane mode
Single-lane mode
Dual-lane mode
Single-lane mode
*2 *3 *4
*2
*1
NPM-D3A
3.6s
L 50
mm
× W 50
mm
∼ L 510
mm
× W 300
mm
L 50
mm
× W 50
mm
∼ L 510
mm
× W 590
mm
*No 0s when cycle time is 3.6 s or less
*When selecting short conveyors
0s
3-phase AC 200, 220, 380, 400, 420, 480 V 2.7 kVA
0.5 MPa、100 L /min（A.N.R.）
W 832
mm
× D 2 652
mm
× H 1 444
mm
1 680 kg（Only for main body:This differs depending on the option configuration.）
46 000 cph
（0.078 s/ chip ）
±37 μm/chip
Lightweight 16-nozzle head V3
（ Per head ）
High production mode[OFF]
High production mode[ON]
Placement accuracy（Cpk≧1）
38 000 cph
（0.095 s/ chip ）
Placement head
Max. speed
Taping
Component dimensions
0402
chip
∼ L 6 × W 6 × T 3
*6
*6 *6*7
03015
/
0402 chip ∼ L 6 × W 6 × T 3
± 30 μm / chip
（± 25 μm / chip ）
*5
Tape：4 / 8 / 12 / 16
mm
Max. 68 （ 4、8
mm
tape、Small reel）
*It may not conform to Machinery Directive
and EMC Directive in case of optional
configuration and custom-made specification.
PCB
dimensions
PCB
exchange
time
*
*
（mm）
Component
supply
* Placement tact time,inspection time and accuracy
values may differ slightly depending on conditions
*Please refer to the specification booklet for details.
*1：Due to a difference in PCB transfer reference,
a direct connection with NPM (NM-EJM9B) /
NPM-W (NM-EJM2D) / NPM-W2 (NM-EJM7D)
dual lane specs cannot be established.
*2：Only for main body
*3 : Dimension D including feeder cart
*4：Excluding the monitor, signal tower and ceiling fan cover.
*5：±25 μm placement support option.
（Under conditions specified by Panasonic）
*7：Support for 03015 mm chip placement is optional.
  （
Under conditions specified by Panasonic：Placement accuracy ±30 μm / chip ）
*6：The 03015/0402
mm
chip requires a specific nozzle/feeder.
