Operational Humidity Set Range 0.5% - 95% RH (Ambient to Set V alue) T emperature Set Range (Optional) 15 °C - 45 °C - 60 °C - 100 °C (Ambient to Set V alue) Time to Reach to Set Humidity Level <15 min. with one Dryer…

100%1 / 5
Physical
External Dimensions (WxHxD)
XT Line Cabinets 1200 x 1990 x 750 mm
Internal Dimensions (WxHxD)
Non-Insulated Insulated
1197 x 1654 x 630 mm 1178 x 1634 x 630 mm
Net Volume
Non-Insulated Insulated
1250 lt 1215 lt
Weight (Depends on Conguration) 190 kg
Max. Load Capacity of a Shelf 50 kg
Height from Ground 30 mm
Body Material
Electrostatic Painted Steel,
Stainless Steel Interior Panel
Door Glass 24 mm Insulating Thermal Glass
Standard Doors 4 Doors
Electrical
Voltage 220 - 240 V AC 50 Hz - 110 V AC 60 Hz (±10%)
Current / Max Power 10 A - 16 A (Maximum) / 2200 W Max.
Average Power Consumption 50 W / Hour (Depends on Conguration)
Max Power Consumption / Hour
(Depends on Conguration)
Base Light N2 1
st
Dryer 2
nd
Dryer 45 °C Heater 60 °C Heater 100 °C Heater
XT Line Cabinets 10 W 58 W 5 W 750 W 750 W 1500 W 1500 W 2250
Shelves
Standard Shelves Stainless Steel (10 pcs.) (Adjustable)
Shelf
Capacity
Material Stainless Steel
Maximum / Cabinet XT 36 pieces (2 in a row) (Adjustable)
Minimum Shelf Height 60 mm
Mounting / Demounting With Shelf Holder Parts, No Tools Required
XT Line
(1250 lt)
www.x-tremeseries.com
Operational
Humidity Set Range
0.5% - 95% RH (Ambient to Set Value)
Temperature Set Range (Optional)
15 °C - 45 °C - 60 °C - 100 °C (Ambient to Set Value)
Time to Reach to Set Humidity Level
<15 min. with one Dryer <7 min with double Dryer (values for 1% RH)
Specications
www.x-tremeseries.com
Measurements
Relative Humidity Measurement
Location Cabinet inside (Standard), Cabinet outside (Optional)
Range 0 - 99% RH
Accuracy
± 0.3% RH (0…20% RH) ± 1.5% RH (20…99% RH) (After Calibration)
(Indoor Sensor)
Resolution 0.01% RH < 10% RH - 0.1% RH > 10% RH (Indoor Sensor)
Temperature Measurement
Location Cabinet inside (Standard), Cabinet outside (Optional)
Range -20 - +110 °C
Temperature Measurement
Accuracy ± 0,5 °C (at 25 °C)
Resolution 0.1 °C
Date & Time Date (dd.mm.yy) and Time (hh:mm:ss) display with Real Time Clock (RTC)
Alarm Functions
Alarm Type Standard Internal Buzzer, Optional Alarm Light Bar
Alarm Duration Adjustable, Internal Buzzer: 5 - 255 sec. Alarm L. Bar: 1 - 60 min.
Humidity Level Alarm Adjustable Oset: 0% RH - 40% RH
Temperature Level Alarm Adjustable Time Aer Door Close: 1 - 60 minutes
Door Le Open Alarm Adjustable Time to Alarm: 10 - 240 seconds
Optional Features
Secondary Dehumidier Unit
Advantage 60% decrease in time to reach to set humidity level
Usage As Standby, Sharing Drying Task with Intervals
Heater
Capacity 2 x 750 W
Heating Type Electrical, Heating Elements and Fans
Insulation Material Elastomeric Rubber Foam, Thermal Conductivity < 0,036 W/mK
Control Automatic
Lighting
Location Interior
Capacity & Type LED Lamp for XS Line-Fluorescent daylight for XT and XL Line
Control Automated: Display Touch, Motion Sensor or Door Open Triggered
Light ON Time Aer Last Trigger, Adjustable: 0 - 240 minutes
Automatic Door Lock
Number of Locks 1 Lock per Door
Lock Type Automatic Door Locks by Password, Open / Locked Status Monitoring
Control Access Code Used as Password
Outdoor Sensor
Location Integrated to Body on Top of Right Side of Cabinet
Measurement Relative Humidity, Temperature
Specications Same as Cabinet Inside Sensor, Except Accuracy of ± 1.5% Rh
Alarm Light Bar
Type Buzzer and Two-Colored Lights, Magnetic Base
Buzzer Noise Level 70 dB (A)
Light Type and Colors Yellow and red, 12 V, 5 W lamps
Shape and Visibility Cylindrical, 360° View
Mounting Easy Attachable with Magnetic Base Plate, Built-In Screw Holes
Connection 4-Pin XLR Connector Behind Cabinet
Version 3.0 Soware - Industry 4.0
Display - Control Panel
Type Touch Screen Display
Active Area 7"- (155 x 86mm)
Resolution 800*480 Pixel
Datalogger
Capacity 2 GB
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network), USB Flash Disk
USB (AF Type) Connector Right and Le Side of the Cabinet
RMS (Remote Monitoring)
Monitoring via PC, Phone, Tablet
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network)
