Version 2
Page 14 / 16 24.11.2021
Pos. Item no. Description Part marking
03014048-01 QSY-6 Y-STECKVERBINDUNG STANDARD PARTS
00308279-01 DISTANCE BOLT M3X20 I/O HEX5,5
ST ZC
STANDARD PARTS
03051003-01 ONE TOUCH FITTINGS SERIES
KQ2L06-U02
32 03020068S08 FCU X-SERIES
33 03052576-02 USED TAPE CHANNEL SPARE PART
34 03006050-01 COVER PLATE
35 03017800-01 BRACKET
36 03021044-01 NC DETACHABLE BACKING PLATE SPARE PART
37 03021079-01 NOZZLE CHANGER SHIM PLATE SPARE PART
38 03006335-02 USED TAPE CHANNEL
39 03009547-03 RIGHT SIDE PANEL, USED TAPE
CHANNEL
40 03007447-01 ROUND CORD, 475 LONG
41 03017820-01 TRACK RULER, PITCH 11.8 / X
FEEDER
SPARE PART
42 03021163-02 LEFT SIDE PANEL, USED TAPE
CHANNEL
43 03023092-01 USED TAPE CHANNEL, INTERNAL
44 03023144-01 USED TAPE CHANNEL, EXTERNAL
(BOTTOM)
45 03023168-01 USED TAPE CHANNEL, EXTERNAL
(TOP)
46 03023337-01 USED TAPE CHANNEL, INSERT (TOP)
47 03023309-01 USED TAPE CHANNEL, INSERT
(BOTTOM)
48 03039517-02 DETACH. BACKING PLATE F.
NOZZLE REJECT D
49 03039514-02 SHIM PLATE FOR NOZZLE REJECT
DEVICE
SPARE PART
03050316-01 GUIDE COMPONENT REJECT BOX
RIGHT
03050285-01 GUIDE COMPONENT REJECT BOX
LEFT
50 03006619-06 CO TROLLEY DOCKING UNIT, X-
SERIES
51 03047616-01 CYLINDER 50X60 SA-207074 SPARE PART
52 03002876-01 SHORT STROKE ZYLINDER 20X10 SPARE PART
54 00353412-01 ONE-WAY FLOW CONTROL SPARE PART
Version 2
Page 15 / 16 24.11.2021
Pos. Item no. Description Part marking
VALVEAS2201F-01-04S
55 03006245-01 THROTTLE VALVE SPARE PART
56 00845049-01 DIN912-M5 X 40-8.8
58 00845078-01 DIN912-M8 X 30-8.8
59 03015907-01 SLEEVE
60 00845060-01 DIN912-M6 X 25-8.8
03053235-01 CABLE HARN. CPL. DOCK. UNIT X-S
CAN-NODE
SPARE PART
03053220-01 CABLE SET DOCKING UNIT X-SERIES
CAN-NODE
03053222-01 CABLE DOCKING UNIT X-SERIES:
CAN BUS
03053223-01 CABLE DOCK.UNIT X-SERIES:
NOZZLE STATION
03053224-01 CABLE DOCKING UNIT X-SERIES:
FCU SIGNAL.
03053225-01 CABLE DOCKING UNIT X-SERIES: NC-
CAN-NODE
SPARE PART
03053226-01 CABLE DOCK. UNIT X-SERIES:FCU
DOCK.UNIT
03053227-01 CABLE DOCKING UNIT X-
SERIES:VALVE ON/OFF
03053228-01 CABLE DOCKING UNIT X-SERIES:
SAFETY
03053229-01 CABLE DOCK.UNIT X-SERIES: COMP.
REJ. BOX
03021042-01 CABLE X-SERIES HF R2 / ADAPTER
CONNECTOR
82 03019065-01 SAFETY SWITCH AZ 335-03ZK-2737
M20 3NC
SPARE PART
61 03053231-01 VALVE COMPL.
03032849-01 ZIPPERTUBING D=35MM BLACK
62 03004200-01 INTERFACE COMPR. AIR
DISTRIBUTOR.,INPUT
SPARE PART
63 03051005-01 CABLE RUN
64 03053171-01 RETAINING ANGLE PLUG-IN
CONNECTION REJECT BOX
03051652-01 CABLE, X-S/POWER/ DATA,EDIF
UNLOCK. RAIL
SPARE PART
00845027-01 DIN912-M4 X 16-8.8
Version 2
Page 16 / 16 24.11.2021
Pos. Item no. Description Part marking
66 00845030-01 DIN912-M4 X 30-8.8, VERCU/NI
67 03002681-01 DOWEL SCREW 10*40/M8
68 00845076-01 DIN912-M8 X 20-8.8
00095280-01 DIN 933-M6 X 30-8.8
69 00306629-01 DIN912-M5 X 6-8.8
70 03011582-02 FEEDER UNLOCK DEVICE 40-WAY SPARE PART
03035877-01 GROUNDING, M5 SPARE PART
71 03039249-01 WASTE SLIDE COMPLETE SPARE PART
72 03023039-03 RETAINING BRACKET F. ONE-WIRE
HUB, NC
73 03053345-01 COVER SHEET COMPL
74 00373391-01 T-CONNECTION QST-6-4
76 03003719-06 BOX
77 03019062-02 INPUT-CONTROL UNIT X-SERIES SPARE PART
78 03020549-02 30V-DC-DC-CONVERTER COMPL. X-
SERIES
SPARE PART
79 03020513-03 30V-DC-DC-CONVERTER FOR
COMPONENTS FEEDER
80 03020861-01 SUPPORT PLATE FOR DC-DC-
CONVERTER COMPONENTS FEEDER
COMPLETE
81 03049954-01 COMPONENT REJECT BOX UP TO
6X6
SPARE PART
