General
Design Basic Contact Probe
Family F100
Pitch [mm/mil] 2.54 / 100
Electrical specifications
Typical contact resistance [mOhm] 20.00
Mechanical specifications
Preload [cN] 150.00
Spring force [cN] 300.00
Nominal travel [mm] 4.30
Maximum travel [mm] 6.40
Dimensions
Total length [mm] 33.30
Tip style diameter [mm] 0.60
Barrel diameter [mm] 1.37
Materials & surfaces
Tip style 10
Plunger material Steel
Plunger plating Longtime Gold
Barrel material Bronze
Barrel plating Gold
Spring material Spring steel
Spring plating Silver
Accessories
Basic Contact Probes
F10010S060L300
Order code 1004175
Family drawing
Tip style 1
