ro400fc . ro400fc . -c ro300fc . C ontrol Board c ounter Optional with sensor or standard with SMEMA option Gas temp. adjustment Adjustable from 20° t o 290°C (68° to 554°F) for each zone PCB PCB handlling Mesh Pin chain…

FULL CONVECTION

REFLOW OVENS

Introducing - The Lizard - Demands for

a modern oven are not only in soldering

and curing.

3-5 zone relow, up to 400 mm process width

Mesh belt or pin chain conveyor

Soldering or curing - Full convection heating

for even temperature distribution

For solder pastes with or without lead

Low thermal stress, eficient heat transfer

Temp. metering in heating & cooling zones

Integrated microprocessor for proile control

Highly reproducible soldering conditions

Built-in overheat security switches

CELL SOLUTION

LINE SOLUTION

Closed loop controlled conveyor drive system

Integrated microprocessor control with LCD

productivity.

combined process

lead-free process.

controlled process.

flexible process.

secure process.

MULTITALENT SOFTWARE RO-CONTROL – PC software for simulation, control,

measurement and documentation of perfect solder proiles, job planning, setup

optimisation, easy assistant process support, Integrated microprocessor control

with LCD for easy operation, and more

RO-CONTROL Software Simulation and unlimited storage space for programs

Ecient Cooling Two highly ecient blowers cool down the PCB

Transport Systems Mesh belt or chain conveyor system (with middle support)

SMEMA Integration Link the RO400FC with any other compatible equipment

Process Control Optional ﬂying thermocouples, temperatures can be recorded

Soldering of complex SMD boards requires a well-

controlled process. Demands are not only in

soldering, but also in zone regulation, storing of

proiles and the extra high air circulating volume.

Full operator support - The integrated micropro-

cessor control provides an easy-to-use operator

interface and storage capacity for different solder

proiles. All options and accessories retroittable.

The convection technology applies the same

temperature all over the pcb or substrate, making

programming as easy as possible. Transport width

adjustment of the chain conveyor is motorized.

ro400fc. ro400fc.-c ro300fc.

Control Board counter Optional with sensor or standard with SMEMA option

Gas temp. adjustment Adjustable from 20° to 290°C (68° to 554°F) for each zone

PCB PCB handlling Mesh Pin chain Mesh (or Pin chain -c)

Substrate width 10-400 mm (0.39-15.8”) 60-400 mm (2.4-15.8”) 10-300 mm (0.39-15.8”)

Conveyor Conveyor speed range 100-800 mm/min (3.9 - 31.5”/min); Slow speed 10-200 mm/min

Process Heated length 1‘620 mm (63.8”) 1‘160 mm (45.7”)

Machine Footprint 2‘800 x 914mm (110.2 x 36“) 2‘000 x 710 mm (78.8 x 28”)

Essemtec AG

Mosenstrasse 20

CH-6287 Aesch/LU

Switzerland

FLEXIBLE SMT

SOLUTIONS

CHOOSE YOUR

PREFERENCES

Phone: +41 (0)41 919 60 60

Fax: +41 (0)41 919 60 50

Mail: info@essemtec.com

Wildlife consistently shows us with breathtaking ﬂexibility how nature can

adapt itself to the many dierent demands of its environment; that is what

inspires us! Essemtec AG is a privately owned company with its development

and production site in Switzerland. The product portfolio comprises of pro-

duction equipment for electronic assembly and more. Our high tech solu-

tions can be adjusted quickly and easily to meet wide ranging requirements;

we are therefore able to respond to all manner of customer requests. That’s

why “naturally adaptive” is our motto across all ranges.
