EN TopRouter
Key features
- High speed, low stress separating process
- Top side routing and/or sawing
- Linear motor technology
- TS1 HMI
- Router bit breakage detection and life monitoring
- Two position turntable: Unloading/Loading during
depaneling process
- Ionizer
- Automatic Router bit exchange
Options
- Fiducial recognition
- 1D/2D Code Reader
- Fixture detection
- Routing program generator based on .DXF or gerber
data
- Traceability software (CamX)
- Twin Spindle (Sawing and Routing side by side)
- Pass/Fail Indication using beamer
TopRouter
Depaneling System
The off-Line depaneling system TopRouter is
developed for modular structured productions with
a high variety of products.
This flexible usage is guaranteed through a quick
change of product-specific carrier.
Routers and/or saw blades are at hand and
guarantee an optimal depaneling of the PCB.
