Collect and place head RVC 6-nozzle
Page 24 / 26 22.11.2021
Pos. Item no. Description Part marking
169 00351497-04 VALVE LIFTER SP-12
170 00359382-01 SPRING O-RING WEAR PART
171 00319748S04 12ER-SEGMENT CPL. DLM2 SPARE PART
172 00319352S02 AIR SUPPLY
173 03009556S02 DISTRIBUTOR DISK PAS-LX RVM-6
CPL.
SPARE PART
174 00341183S01 CONNECTION HOSE, DLM1 SPARE PART
175 00320023S01 O-RING 2.5X1 NBR 70 B WEAR PART
176 00303338-01 DIN 6325 - 1,5M5 X 5-ST
177 00322912-01 DIN912-M2 X 8-A2-70
178 00304316-01 DIN912-M2 X 3-A2-70
179 00201348-01 DIN 84-M1,6 X 4-A2
180 00303193-01 DIN912-M3 X 8-A2-70
181 00335990S06 DIGITALER ROTAY ENCODER C+P12
/ DLM
SPARE PART
182 00308108-01 DIN912-M2,5 X 8-A2-70
183 00334724-01 DISTANCE BOLT
184 00322562-01 DIN912-M2,5 X 4-A2-70
185 00325298S03 COVER F. READER BOARD
(PLACEMENT HEAD)
SPARE PART
00368154-01 COMPRESSED AIR HOSE BLAST AIR
SP6 DLM2
188 00335989S02 VACUUM GENERATOR COMPLETE /
DLM1
SPARE PART
189 00337688S01 VACUUM GENERATOR BASE UNIT
ASSY/DLM1
SPARE PART
190 00319420S03 VACUUM NOZZLE D = 1.5 WEAR PART
191 00319423S02 VACUUM NOZZLE WEAR PART
192 00336674S01 DISTRIBUTOR, DLM1 SPARE PART
193 00325349-01 DIN912-M3 X 16-A2-70
194 00325302S04 VACUUM GENERATOR COVER SPARE PART
195 00325312-01 DIN912-M2,5 X 6-A2-70
196 00359582S01 SILENCER, ANTI-STATIC WEAR PART
197 00320047S01 O-RING 10X1.5 NBR 70 B WEAR PART
198 00320048S01 O-RING 14X1.5 NBR 70 B WEAR PART
199 00342864S03 HOSE, VACUUM STOP CIRCUIT
(HEAD)
Collect and place head RVC 6-nozzle
Page 25 / 26 22.11.2021
Pos. Item no. Description Part marking
200 00342867S03 HOSE, VACUUM PLACEMENT
CIRCUIT (HEAD)
201 00320962-01 PRESILENCER
202 00320961S01 COVER WITH SET SCREW F.
VACUUM GENERATOR
SPARE PART
203 00338012-01 SET SCREW /DLM1
204 00347857S02 VACUUM MEASURING BOARD II SPARE PART
205 00342868S03 HOSE, QUERY STOP CIRCUIT (HEAD)
206 00342869S03 HOSE, QUERY PLACEMENT CIRCUIT
1,5X3,5X112
207 00345074-01 DISTANCE BOLT TYPE B I/A-
M2.5X15-ST ZN N
208 00337340S01 QUICK-RELEASE FASTENER 4.3/3 SPARE PART
210 00343022S01 O-RING 30X1 WEAR PART
211 00350662S01 O-RING 10X1 VITON 75 WEAR PART
212 00350661S01 O-RING 8X1 VITON 75 WEAR PART
213 00354836-01 BAG ADAPTER PLATE
214 00363164-01 RUBBER BONDED METAL BUFFER
(REWORK)
SPARE PART
215 00095105-01 HEXAGON SOCKET HEAD CAP
SCREW
216 00313069-01 DIN912-M4 X 10-A2-70
217 00342876-01 SCHNORR LOCKING WASHER 4.3,
V2A HN 160
SPARE PART
218 00336791S04 COMPONENTS CAMERA 24X24 Spare Part
219 00325049S01 PROTECTION COVER SPARE PART
220 00332915S01 CABLEHOLDER SPARE PART
221 00313069-01 DIN912-M4 X 10-A2-70
222 00350588S04 12ER- SLEEVE WITH BALL FIXING
COMP.
SPARE PART
223 00322602-06 NOZZLE TYPE 704/904/3004 CPL. /
CERAMIC
WEAR PART
224 03001806-01 COVER IN FRONT COM. / DLM SPARE PART
225 00353198-02 HEAD BOARD COMPLETE S25 SPARE PART
00344486-01 GANTRY - HEAD DISTRIBUTOR S23
00344485-09 PROCESSOR BOARD 80C515C SPARE PART
00344488S03 SM BOARD MODULAR SPARE PART
00344489-02 VISION BOARD MODULAR SPARE PART
Collect and place head RVC 6-nozzle
Page 26 / 26 22.11.2021
Pos. Item no. Description Part marking
226 00351063-01 CABLE:COMP.ILLUMI.MODULAR SPARE PART
227 00321550-03 GANTRY CABLE (CAMERAS) SPARE PART
228 00321553-03 GANTRY CABLE (HEAD AXES) SPARE PART
229 00321554-03 GANTRY CABLE (X-TRACK / CAN-
BUS)
SPARE PART
230 00321555-04 GANTRY CABLE (DP1-AXIS) SPARE PART
231 00321556-03 GANTRY CABLE (STAR / Z-AXES) SPARE PART
00116113S01 SET BALL SLEEVES FOR 12 NOZZLE
REV.-HEAD
SPARE PART
00350588S04 12ER- SLEEVE WITH BALL FIXING
COMP.
SPARE PART
