8 | Nordson DAGE Explorer X-ray Inspection Simplicity as S t andard Quickly inspect a high mix of electr onics pr oducts. Explor er ™ one enables operators and occasional users to perform quality inspection quickly , eas…
6 | Nordson DAGE Explorer X-ray Inspection 7 | Nordson DAGE Explorer X-ray Inspection
Unique, integrated technology
Explorer one features proprietary technology at every step
of the image chain, from generating and detecting X-rays
through to image enhancement and measurement. Every
component has one purpose: to create the highest quality
images for electronics inspection.
Quadra
®
X-ray tube technology
High quality images begin
with the X-ray source.
Explorer one uses QuadraNT
®
X-ray tube technology, also
used in our Quadra series
of X-ray inspection tools, to
deliver market leading image
quality at every power level,
maintenance free.
Designed for electronics
See features as small as 2 μm. This is the difference between
detecting a bond is present and seeing it in high detail.
The AspireFP
®
one at panel detector, developed specically
for Explorer one, is optimized to give the highest contrast in
electronics samples.
Up is always up
Never lose your way. Explorer one’s unique dual axis
oblique viewing keeps the board orientated up, whichever
side you look at it from. The sample is never rotated.
Turn Images into Solutions
Explorer™ one enables you to quickly
understand the quality of your products by
delivering the clearest X-ray images. Market
leading image quality makes it quick and
easy to locate and qualify potential defects
and make pass/fail judgements fast.
Bring out the nest details
Over 30 advanced lters bring out the sharpest images and
show the nest details, allowing you to nd features and
defects faster.
Multicolor LED with blown bond wire and detached die.
Oblique views from below (left image) and from the side (right image) make it easy to
conrm BGA reow quality.
8 | Nordson DAGE Explorer X-ray Inspection
Simplicity as Standard
Quickly inspect a high mix of
electronics products. Explorer
™
one
enables operators and occasional
users to perform quality inspection
quickly, easily and with minimal
training so you can maximize your
throughput.
Fast
Explorer one gives the real-time image feedback
you need to navigate around products and nd
defects fast.
Automated inspection routines
Save time inspecting batches of boards with
automatic inspection routines. Program a routine
once, using component layout design data to
assist, then simply insert the board and click to go.
Reports, generated in seconds may be saved
locally or on a central database.
Compliance
In-built tools for dimension measurement, BGA
void analysis, bump diameter and roundness and
through hole lling make quick work of nding
and characterizing defects, helping you achieve
IPC-A-610 and IPC-7095 compliance.
Never lose your way with the
component location overlay.
Move straight to any device
on the board with a single
click. Know which part you are
inspecting as you move around.
9 | Nordson DAGE Explorer X-ray Inspection
Super Compact Footprint
Our smallest, lightest X-ray
inspection system yet, Explorer
™
one
balances board size and system
footprint, giving you a system which
is easy to site and quick to install, so
you can be up and running fast.
Make the most of your space
Our unique double oblique angle detector
geometry inspects 300 x 300 mm boards from
every side without requiring a size restricting
circular rotation table.
Peace of mind
Nordson’s worldwide support network ensures
help is always at hand, so you get the most from
your Explorer throughout its entire lifecycle.
Nordson’s regional service centers and
established support network offers a fast,
regional response.
Reduce your downtime and costs
Explorer one is a maintenance free, oil free
X-ray inspection system. Regular preventative
maintenance visits are not required to guarantee
optimum X-ray performance. Simply inspect and
radiation check annually.
