RDS Solar Dryer
Ready for complex pastes
Nowadays manufacturers are more and more focussed on
the quality of the drying process within the crystalline silicon
solar cells production. Good drying means excellent adhesion
of the printing pastes to the wafer. The drying recipe optimi-
zation, possible only with a versatile oven, is crucial to get to
this target. The range of Rehm solar dryers covers the need
of the industry with its peak temperature up to 300°C for the
standard RDS version and 400°C for the RDS Speed version.
Both systems work with a hybrid heating system which gua-
ranties a optimum drying performance. The system combi-
nes heat transfer with radiation and convections in a perfect
synergy
Rehm Thermal Systems GmbH | Leinenstrasse 7 | 89143 Blaubeuren, Germany | www.rehm-group.com
up to 400 °C
Facts and gures
Detail Information of the RDS Solar Dryer
System Types
Overall Length:
Overall Width:
Footprint:
Weight:
max. Temp. Drying Radiation
max. Temp. Drying Convection
Heating Zones Drying:
Cooling Type:
Cooling Zones Length:
Conveyor Width:
No. of Transport Lanes:
Lane Pitch:
Belt Speed Range:
Belt Type / Conveyor Material
Throughput:
Case of Application:
Transport Height:
RDS 2100
3,5 m
1,25 m
4,4 m²
approx. 1500 kg
300 °C
300 °C
5
Air
630 mm
460 mm
dual lane
210/270mm
1 – 8 m/min
Mesh Belt / Stainless
Steel
4000 wph
Ag print drying
930 +/-50 mm
RDS 3000
4,5 m
1,25 m
5,6 m²
approx. 2300 kg
300 °C
300 °C
7
Air
750 mm
460 mm
dual lane
210/270mm
1 – 8 m/min
Mesh Belt / Stainless
Steel
4000 wph
Al print drying
930 +/-50 mm
RDS SPEED
5,4 m
1,60 m
8,6 m²
approx. 2800 kg
400 °C
300 °C
7
Air
1500 mm
540 mm
dual lane
350mm
1 – 11,5 m/min
Mesh Belt /
NiChrome V
7200 wph
Al/Ag print drying
930 +/-50 mm
