M ODEL: BS281E-V SMT-PICK&PLACE MACHINE Perfect for prototyping & small volume production Automatic detection of loose components High Accuracy and high Flexibility from 0201 up to 0.5 mm ne pitch 64 intelligent…
MODEL:
BS281E-V
SMT-PICK&PLACE MACHINE
Perfect for prototyping & small volume production
Automatic detection of loose components
High Accuracy and high Flexibility
from 0201 up to 0.5 mm ne pitch
64 intelligent Auto Tape Feeder w. Quick Scan Function
Belt-driven in X-Y direction
Up to 3.000 CPH
COGNEX Alignment System „Vision On the Fly“
Digital Bottom Vision Kamera for
ne pitch QFP & BGA
Automatic Reference Point Recognition
Dispenser System
Vision Inspection
Universal CAD Conversion
Barcode Reader for Feeder setup
Unbeatable
Service
Worldwide
for you!
Specialist in small
and medium-sized
manufacturing.
All from
one hand.
Innovative
Features
Quality &
innovation at
a fair price.
Intelligent feeders in all common sizes.
Component spectrum from 0201 to
100x150 mm, component height
up to 15mm
Components on tapes, tubes, cut tapes,
loose components and trays can be
processed.
*We reserve the right to make changes without notice.
MODEL:
BS281E-V
SMT-PICK&PLACE MACHINE
SPEZIFICATION:
• Number of Heads (Vision on the Fly): 1
• Placement rate (under optimum condition):
3000 CPH, 2500 CPH (IPC 9850)
• Feeder capacity (8mm): up to 64 Tape Feeders
• IC Tray capacity: up to 3 Wae Trays
• Component Sense: Vision detection
• Component Size:
Handled by digital head camera:
- smallest: 0.6 x 0.3 mm
- largest: 16 x 14 mm
Handled by xed digital Bottom Vision Camera:
- largest: 150 x 100 mm
• Resolution:
- X/Y Axis: 0.005 mm
- Z Axis: 0.01 mm
• Rotation: 0° to 360° (0.09°/step)
• Placement Accuracy: +/- 0.05 mm
• X/Y Repeatability: +/- 0.01 mm
• Placement Area:
- without Wae Tray: 320 x 415 mm
- with 1 Wae Tray: 320 x 270 mm
• Programming:
- Direct Input
- Teach-In by Camera
- CAD Access (option)
- Barcode Reader (option)
• Industrial PC with Windows 10
• Power Supply: 230VAC
• Power: 700W
• Pressure: 75 psi (5.5 bar), max. 100L/min
• Machine Size: 980 x 1025 x 720 mm (L x W x H)
• Weight: 165kg
