YS12P_YS12F_YG12F_KKD-M715H-01_MAINTE_PARTS_SET_20150511_.pdf.pdf
No. Part No. Part Name Q'ty Remarks YS12F Head No.2 1 2 3 4 5 6 7 YS12P,YS12F,YG12F:KKD-M715H-01 MAINTE.PARTS SET K46-M8527-C0 90990-17J010 KG7-M7137-A0 90200-10J030 90990-08J016 90990-17J081 90990-17J082 FIL TER O-…
No. Part No. Part Name Q'ty Remarks
YS12F Head
No.2
1
2
3
4
5
6
7
YS12P,YS12F,YG12F:KKD-M715H-01 MAINTE.PARTS SET
K46-M8527-C0
90990-17J010
KG7-M7137-A0
90200-10J030
90990-08J016
90990-17J081
90990-17J082
FILTER
O-RING
LEAF SPRING
O-RING
SCREW, PAN HEAD
O-RING
O-RING
5
10
10
5
10
2
1
4
5
3
5
3
1
2
2
5
3
5
3
6
NOZZLE 304A/315A ASSY
NOZZLE 307A/318A ASSY.
7
CS1102002J/E-002
YAMAHA MOTOR CO.,LTD.IM Operations
‘2015 Added
‘2015 Added
