General
Family H875
Mechanical specifications
Internal thread M1.6
Dimensions
Total length [mm] 29.50
Press ring diameter [mm] 2.20
Outer diameter [mm] 2.00
Collar height [mm] 0.20
Accessories
H875
Order code 1001866
Family drawing
All measurements are in mm.
