Application Application recommended Recommended temperature Recommended time Capacity per shift PCBs 35 – 55°C 15 min. 768* Stencils 20 – 40°C 15 min. 48 Pumprints 40 – 55°C 38 min. 28 4 INDIVIDUAL PROCESSES CLEANING PAR…
Dimensions (w x l x h) 1691 x 3240 x 2145 mm
Weight 1400 kg
Ø energy consumption per 1 cycle 3,14 kWh
0,2 - 0,4 l
Max. dimensions of the cleaned parts 2 x (98 x 810 x 740 mm)
20 - 100 μm
5 - 20 μm
Operating pressures Cleaning 2 Bar
Pre-rinsing 1 Bar
Rinsing 1 Bar
200 l/min
From ambient temperature to 60°C
From ambient temperature to 60°C
From ambient temperature to 60°C
0 – 40, 0 – 400, 0 – 2000 μS/cm
Temperature range setting of the drying From ambient temperature to 80°C
Noise level < 70 dB
Device control PLC + 8,4“ touchscreen + 5,7“ touchscreen
TECHNICAL PARAMETERS
Power supply 400 V, 50Hz (3+N+PE)
Power connection EU 63 A
Pmax 35 kW
Connection to central air pressure Pipe Ø 6 mm and Ø 10 mm
Recommended working pressure 5 Bar
Exhaust pipe diameter 2 x Ø 100 mm
Exhaust pipe capacity 580 m
3
/h
Volume of the storage tanks for cleaning 150 l
Volume of the storage tanks for pre-rinsing
and rinsing
2 x 150 l
Service space required around the device 600 mm
INSTALLATION REQUIREMENTS
www.dct.cleaning
InJet
®
DOUBLE TRIPLE 388 CRRD
TECHNICAL DATA SHEET
Application Application
recommended
Recommended
temperature
Recommended
time
Capacity
per shift
PCBs
35 – 55°C 15 min. 768*
Stencils
20 – 40°C 15 min. 48
Pumprints
40 – 55°C 38 min. 28
4 INDIVIDUAL PROCESSES
CLEANING PARAMETERS
highly recommended
eurocards (100 x 160 mm) per 8 hours (work shift)
*
C R R
EF2
EF1
C
CLEANING
PRE-RINSING
R
R
D
RINSING
DRYING
EXTERNAL FILTRATION 1
EXTERNAL FILTRATION 2
www.dct.cleaning
InJet
®
DOUBLE TRIPLE 388 CRRD
TECHNICAL DATA SHEET
EF1
EF2
InJet
®
DOUBLE TRIPLE 388 CRRD
TECHNICAL DATA SHEET
STANDARD EQUIPMENT
3 arm rotation - electric powered - cleaning
2 arm rotation - electric powered - rinsing
3 process chambers - fully automatic solution
3 level of logging - operator, maintenance, technician
PLC controller + 8,4" touchscreen display + 2
nd
touchscreen display 5,7“ - output chamber
Chimney ap - electronically controlled
Manipulation wheels - lockable
Mechanical ltration
Heating - cleaning uid
Heating - rinsing uid
Hot air drying
2 hot air blowers - drying
15 years warranty - complete stainless steel construction:
- Pipings, Frame, Mechanical ltration, Process chambers, Storage tanks
3 years warranty - components
100% closed loop system
100% separated processes
Stainless steel nozzles
Designed for easy maintenance and service of complete machine
Emergency stop button additional
Pneumatic door lock
Connection ready for external Sandwich ltration
Liquid and lter replacement notication - cycle counting
Spraying uid pressure - continuous measurement
Smart warning - low uid level
Smart warning - low or high pressure level
