MODEL:
BA385E1-V
SMT-PICK&PLACE MACHINE
Unbeatable
Service
Worldwide
for you!
Specialist in small
and medium-sized
manufacturing.
All from
one hand.
Innovative
Features
Quality &
innovation at
a fair price.
Intelligent feeders in all common sizes.
Component spectrum from 01005 to
100x150 mm, component height
up to 15mm
Components on tapes, tubes, cut tapes,
loose components and trays can be
processed.
Perfect for small & medium volume production
Automatic detection of loose components
High Accuracy and high Flexibility
from 01005 up to 0.3 mm ne pitch
128 intelligent Auto Tape Feeder w. Quick Scan Function
Ballscrews in X-Y direction
Up to 4.500 CPH
COGNEX Alignment System „Vision On the Fly“
Digital Bottom Vision Kamera for
ne pitch QFP & BGA
Automatic Reference Point Recognition w. digital camera
Dispenser System
Vision Inspection
Universal CAD Conversion
Barcode Reader for Feeder setup
EtherCAT Bus System
*We reserve the right to make changes without notice.
MODEL:
BA385E1-V
SMT-PICK&PLACE MACHINE
SPEZIFICATION:
• Number of Heads (Vision on the Fly): 1
• Placement rate (under optimum condition):
4500 CPH, 3400 CPH (IPC 9850)
• Feeder capacity (8mm): up to 128 Tape Feeders
• IC Tray capacity: up to 2 Wae Trays
• Component Sense: Vision detection
• Component Size:
Handled by digital head camera:
- smallest: 0.4 x 0.2 mm
- largest: 16 x 14 mm
Handled by xed digital Bottom Vision Camera:
- largest: 150 x 100 mm
• Resolution:
- X/Y Axis: 0.005 mm
- Z Axis: 0.01 mm
• Rotation: 0° to 360° (0.09°/step)
• Placement Accuracy: +/- 0.03 mm
• X/Y Repeatability: +/- 0.01 mm
• Placement Area:
- without Wae Tray: 435 x 430 mm
- with 1 Wae Tray: 435 x 270 mm
• Programming:
- Direct Input
- Teach-In by Camera
- CAD Access (option)
- Barcode Reader (option)
• Industrial PC with Windows 10
• Power Supply: 230VAC
• Power: 2400W
• Pressure: 75 psi (5.5 bar), max. 100L/min
• Machine Size: 1270 x 990 x 1355 mm (L x W x H)
• Weight: 710kg
V2.0
