As the market leader in wire bond inspection, Viscom no w offers 3D inspection of thin wires for the first time . This new process featur es a smar t combination of 3D bond inspection and very high resolution telecen tri…
As the market leader in wire bond inspection, Viscom now offers
3D inspection of thin wires for the first time. This new process
features a smart combination of 3D bond inspection and very
high resolution telecentric optics, which enables even the most
complex bond layouts to be reliably inspected. Bond wires with a
diameter down to 20μm can be inspected.
Exceptional inspection scope in 3D
Depending on the application, Viscom can accurately inspect
specified loop heights for bonding wires in printed circuit board
design using its new 3D technology. With the acquired height
information it is also possible to reliably detect the distance be-
tween wires crossing one another in order to ensure risk-free and
error-free assembly operation . Even heights of wedges concealed
under bonding wires can be reliably inspected using the Viscom
3D bond inspection. Other applications include determining the
distance between wires and chips as well as reliably detecting so-
called lifters, the balls or wedges of which have no connection to
the contact surface and therefore have no electrical function. The
3D information can also be used to check specified wire lengths
by determining the exact course of the wire.
To summarize, 3D bond inspection from Viscom offers an ideal
extension to inspection depth for even more reliable bond in-
spection of complex assemblies.
3D Bond
Reliable 3D bond inspection
down to 20 µm wire diameter
Unique inspection scope with
best mix of 2D and 3D methods
Quickest inspection times
at the highest inspection depth
Inspection of concealed wedges
3D Bond
3D Wire Bond Inspection
for Even Greater Inspection
Reliability
www.viscom.com
Bent wires (left) and thin-wire lift off (right) in 3D view
Headquarters:
Viscom AG
Carl-Buderus-Str. 9–15
30455 Hannover
Germany
Phone: +49 511 94996-0
Email: info@viscom.de
Europe
Viscom France S.A.R.L.
6, rue Saint Simon
Zone du Vert Galant
95310 Saint-Ouen l‘Aumône
France
Phone: +33 134 641616
Email: info@viscom.fr
Asia
Viscom Machine Vision
Pte Ltd.
150 Kampong Ampat/
#01-02 KA Centre
368324 Singapore
Singapore
Phone: +65 62859-891
Email: info@viscom.com.sg
Viscom Machine Vision
Trading Co. Ltd.
2nd oor, Block D
No. 1010 Kaixuan Road
200052 Shanghai
China
Phone: +86 21 616193-68
Email: info@viscom.cn
Americas
Viscom Inc.
1775 Breckinridge Parkway
Suite 500
Duluth, GA 30096, USA
Phone: +1 678 966-9835
Email: info@viscomusa.com
Viscom Inc.
898 B Faulstich Court
San José, CA 95112, USA
Phone: +1 818 4160514
Email: info@viscomusa.com
Viscom Inc.
Av. Vallarta 6503
Concentro Local F-27
Zapopan, JAL. C.P. 45010
Mexico
Phone: +52 333110-1567
Email: info@viscomusa.com
Africa
Viscom Tunisie S.A.R.L.
Rahma Building; App B5,
Block B, 2nd oor
Lac Houran Street – Berges
du Lac
1053 Tunis, Tunisia
Phone: +216 71960584
Email: info@viscom.fr
Hannover
Tunis
Guadalajara
Shanghai
Singapore
Atlanta
San José
Paris
Viscom also works with an extensive network of local representatives and distributors in Europe, the Americas,
