MYP r o L i ne ™ asse m bly so lut ions . Built f or t omor r o w ’ s change - ma k ers . CHA NG E IS I N THE A IR New com po nent s . New prod uc t mixes . And n ow , a fast a nd ﬂ exible as sem bly lin e that keep s yo…

INTUITIVE INTERFACE DESIGN

Of course, no modern production environment is

complete without the most streamlined user

interface. On the MYPro A40™, this means an

all-new graphical interface that raises the visibility

of vital process data while providing simple,

intuitive touchscreen guidance. It makes operator

training simple, day-to-day functions more

accessible and program settings virtually foolproof.

SOFTWARE-DRIVEN AUTOMATION

True to the MYPro™ assembly concept, the MYPro

A40™ includes the richest software suite in the

industry. Standard CFX and ERP interfaces enable

factory-wide connectivity. And MYCenter puts you

in full control with complete material tracking,

proactive replenishment, modern SQL databases

and enhanced process automation.

EASY MATERIAL MANAGEMENT

Mycronic’s modular feeder system is designed for

accuracy, ease of use and convenience. It gains

unrivalled ﬂexibility from a combination of

intelligent feeders and magazines for tapes, sticks

and trays. Our unique Agilis™ feeders with no

moving parts are easier and quicker to load than

any other on the market. And by keeping pre-

loaded Agilis feeders on hand, you can perform

set-ups and changeovers even faster. Since all

Mycronic magazines can be replenished while

the machine is running, you never have to stop

production if you run out of components.

In addition, all magazines and Agilis feeders have

a unique identity that links them to the machine’s

system software. This enables the machine to

recognize the presence, absence and location of

components — a valuable asset when it comes to

keeping track of inventory, since the machine

knows exactly how many components are left on

each tape reel. Reprogramming of pick positions

is also eliminated. Instead, the system software

instantly recognizes the feeder, regardless of

machine or position, and reopti mizes the mounting

program to maintain the highest levels of eciency.

The Mycronic software suite includes:

• Full visibility planning and fast, error-free converting

of CAD and material data

• 100% stock accuracy with scannable feeders and ERP

connection module

• Complete traceability down to individual PCB level

• User-friendly material handling with e-labels for

paperless kitting guidance

• Proactive replenishment monitor with automated

material delivery

Available models and production cells

MYPro A40DX-13: feeder capacity up to 160 x 8mm reels

MYPro A40DX-17: feeder capacity up to 224 x 8mm reels

MYPro A40DX Synergy line:

• Two MYPro A40DX combined into a uniﬁed,

high-volume pick-and-place solution

• 118,000 cph rated top speed

• Feeder capacity up to 448 x 8 mm reels

* All MYPro A40DX models include two MX7 high-speed

mountheads and one MIDAS high-precision mounthead.

THE EVOLUTION OF AN ICON

Same robust frame and feeder technology. All-new

mounthead and user interface. A leap forward in

performance and versatility. Thanks to the all-new,

high-speed MX7™ mounthead technology, the

industry’s most ﬂexible pick-and-place platform

just got turbocharged.

48% HIGHER THROUGHPUT

High-mix meets high-speed. Or rapid proto typing

meets volume production. However you look at it,

the MYPro A40DX™ maintains the industry’s fastest

changeovers while boosting top placement speeds

by up to 48%. Giving high-mix producers far higher

capacity for long series production runs. Or volume

manu facturers the ﬂexibility to take on jobs of any

size without compromising overall cycle times.

Thanks to seven independently controlled pick-

and-place nozzles, the MX7™ mounthead optimizes

every movement to cover a vast range of

applications and component sizes.

MOUNT 6 TIMES LARGER COMPONENTS

Because each of the seven MX7™ nozzles moves

independently in theta and Z axes, they can pick,

rotate and place nearly any imaginable component

with extreme precision. Fine-pitch CSPs, FCs or

BGAs. From components as tiny as 01005 up to

those as large as 45x45x15 mm or as long as

150x40x15 mm. Or stacked, dipped and entirely

new package varieties. Whatever the next job

demands, a series of high-precision vacuum

sensors and a low-impact nozzle mass ensure you

can pick and place a signiﬁcantly broader range of

parts and sizes without damaging, mis-picking or

dropping components.

40,000

cph

59,000

cph

118,000

cph

MX7™ Width / Length

45 x 45 mm

MX7™ Height / Width

15 x 45 mm

HYDRA

high-precision

mounthead

Width 18.6 x

Length 18.6 mm

HYDRA

H 5.6 x W 18.6 mm

MYPro™

MY300DX

Placement speed

Component size (top-view)

Component range improvement for high-speed mounthead

Component size (side-view)MYPro

A40DX™

*MYPro A40DX™

Synergy

Looking to expand your product mix and your production volumes? Now you can.

The MYPro A40™ delivers the high accuracy and fast changeovers you expect

from the icon of agility, together with a dramatic increase in throughput speed.

Whatever jobs tomorrow might throw your way, there’s never been a more

versatile way to scale up production and grow your business.

Bigger volumes.

Bigger opportunities.

The new MX7

™

mounthead

Flexibility. Turbocharged.

At the heart of the MYPro A40™ is the next-generation MX7™ mounthead

technology. The result of several years of in-house development, it

packs a powerhouse of independent motors, sensors and servo control

technologies into a remarkably compact footprint.

NEXT-LEVEL FLEXIBILITY

• Mount six times larger components up to

45x45x15 mm

• Mount long components up to 150x40x15 mm

HIGH-SPEED PERFORMANCE

• 48% faster top placement speeds

• 14 independent Z and Theta motors

PRECISION ENGINEERING

• Low-maintenance modular design

• 7 high-precision vacuum sensors for

low-force placement of less than 2N

The master of high-mix just turned up the volume.

All so you can handle the widest possible range

of components and batch sizes with the highest

productivity and fastest cycle times. Equipped

with the all-new high-speed MX7™ mounthead,

the MYPro A40™ paves a new path forward

towards the future of ﬂexible assembly.

The MYPro A40

™

Flex your potential

Boost

your output:

48% higher

speeds

Expand your

possibilities:

6 times larger

component size

with MX7™

Simplify

your workﬂow:

All-new

intuitive user

interface

MYPro Line

™

assembly solutions.

Built for tomorrow’s

change-makers.

CHANGE IS IN THE AIR

New components. New product mixes. And now, a fast and ﬂexible assembly line that

keeps you several steps ahead of them all.

With MYPro Line™ assembly solutions, there’s virtually no technology, board design or

batch size that can slow your growth. Handle any material ﬂow. Jet any ﬂuid media.

Place any component. And eliminate every defect. All with full vertical and horizontal

connectivity. And industry-leading planning and process control software to make

quick work of even the most demanding build schedules.

More than the sum of their parts, MYPro Line™ assembly solutions combine to form the

market’s most productive just-in-time production environment. Allowing you to master

any mix. Turn up the volume. And embrace whatever changes tomorrow may bring.
