Verification Station S6002

Effective fault processing

without halting AOI

The verification station S6002 allows defect images and features to be

displayed. With it, good and bad can be separated; at the same

time, it can be used to evaluate inspection data.

It connects to the inspection system (AOI/AXI) through a

network. Inspection results are immediately transferred

from the inspection system to the verification comput-

er, where they can be easily and conveniently pro-

cessed with the Viscom HARAN software.

These results are displayed on a monitor screen

as image data, as well as superimposed onto an

overview image of the printed circuit board

with reference to specific position. The color

overview image, displayed by the Viscom

system in true-to-life photo quality, greatly

eases orientation. With this image, 95 % of

defects can be classified without reference

to the actual board. And in the ValidCom-

pareMode, a previously validated good

image is offered for comparison to each

defect image recognized by the AOI. This

good/bad image comparison simplifies

defect evaluation considerably, especially

for the semi-skilled operator. The compar-

ison image can be quickly and easily up-

loaded from a good PCB (Golden Board) at

the AOI.

Essential inspection features can be dis-

played at the verification station as the pro-

gram runs. After defects are classified by the

operator, inspection data can be routed to an

SPC server (Viscom’s Statistical Process Con-

trol), which offers comprehensive statistical

evaluation of the printed circuit board in-

spection. An MES interface allows data transfer

to a traceability system; the resultant statistical

diagrams are accessible online to facilitate rapid in-

tervention into any variations in the production pro-

cess. Documentation of classification results is also ac-

commodated – when required, with recorded images as

well.

Verification station with separate handling module

Close-up of single inspection defects

Several AOI/AXI systems can be linked to one verification station, or

vice versa: analysis results from one AOI/AXI system can be distrib-

uted to several verification stations. Thus, this Viscom module at-

tains the greatest deployment flexibility while maintaining

simple operability.

A further option is cascading inspection results to both an inline

verification station and a downstream repair station. In this configu-

ration, inspection results are validated and defects requiring repair

transferred to the repair station.

To ease defect assessment and prevent faulty classification due to hu-

man error, the system furnishes additional reference images taken

from an angled view. This unique feature permits all defect images to be

readily classified with the assistance of comprehensive image material.

Technical Specifications – S6002

Processor Intel

Core

Main memory 4 GB

Operating system Windows

User interface MFC

Monitor TFT

Special equipment Detached keyboard

Interfaces 1 GB/s LAN

System dimensions 200 x 600 x 600 mm

(7.9" x 23.6" x 23.6") (W x D x H)

Voltage 230 V / 50 (60) Hz, 200 Watt

Comfortable verification station

Realistic, colored overview image

Angular additional images for reliable verification

Directly linked with the SPC server

Verification station with separate handling module

Additional color image with angled view
