MiniBlue ® II Applic a t or F amily 4 | MiniBlue II Applic ator MiniBlue II Slim Only 18mm wide, the MiniBlue II Slim applic ator comes standard with p atented insulated c ov ers, keeping energy c osts low , adhesiv e te…
Interchangeable Modules with EasyOn Interface
MiniBlue II applicators have modules that are physically interchangeable and incorporate
Nordson’s patented hydraulic seal technology. Choose the right module to meet your packaging
line's specic needs.
See The Dierence: Patent Seal Technology
MiniBlue II Applicator | 3
SureBead Modules
Clog-free operation with a self-cle-
aning needle-and-seat design.
Ball-and-Seat Modules
Superior cuto for applications where
ultra-clean operation, including mini-
mized stringing and machine pollution,
is top priority.
EasyOn™ Interface
Reduces installation and
maintenance time,
allowing for quick
changeovers and
maximum uptime
for your line.
Older Standard Module
Inside older hot melt mod-
ules, a needle slides through
a seal (shown in orange).
This creates friction, which
shortens the life cycle of the
module.
MiniBlue® II Applicator
Inside a MiniBlue II module,
the patented seal moves with the
needle through the stroke,
meaning:
• No wear from sliding
• Increased service life
• Cleaner operation without
typical leakage from drainage
hole
MiniBlue® II Applicator Family
4 | MiniBlue II Applicator
MiniBlue II Slim
Only 18mm wide, the MiniBlue II Slim
applicator comes standard with patented
insulated covers, keeping energy costs low,
adhesive temperature consistent, and
operators safe from burns.
Low Prole (LP) Applicators
Even highly specialized applications can take
advantage of the benets of a MiniBlue II
applicator. Low prole applicators are well-
suited for complex or unique use cases.
MiniBlue II Standard
Single & multi-module MiniBlue II applicators
are fully customizable with one to eight modules.
Standard body applicators t a variety of needs
and grow with your packaging line.
Best Choice Retrot Applicators
Quickly swap an existing Best Choice (SolidBlue,
ClassicBlue or SureBead) applicator with a MiniBlue
II to start saving money and adhesive with the least
amount of modications. Retrot congurations
support bar and direct manifold mounting, and keep
the nozzle placement consistent.
Solenoid Options
Waterwash Protection
All MiniBlue II SP solenoids have IPX6 water
ingress protection.
MiniBlue II Applicator | 5
SD Solenoids
These compact, high speed valves are
designed for lines where space is limited. For
use with independent air only.
P1 Solenoids
P1 solenoids oer the industry’s best consis-
tency & speed, capable of 10,000 cycles per
minute (6 ms cycle time and 3 ms dispense)
with some adhesives. The ultra-low pattern
feature improves the life of the applicator on
high speed, high precision packaging lines.
Saturn Platinum (SP) Solenoids
SP solenoids oer an excellent value, capable
of 8,000 cycles per minute (sub 8 ms cycles
and 3 ms dispense times) with certain adhe-
sives. Available in both single module (IA) and
multi-module (CA/PA) formats, SP solenoids
support stitching patterns best when used
with independent air.
