RELENTLESS ALL-

TERRAIN DISPENSER

Introducing – The Tarantula – State of the art

technology with a wide range of applications.

Up to 3 valves simultaneously

5 different valves, large application range

Monitoring sizes & weight of dispense dots

Process control adjustment and dot stabilisation

Up to 145‘000 dots/h (with Piezo Jet Valve)

Up to 2‘000‘000 dots/h in line mode

PCB size 560 x 610 mm, optional 1’800 x 610 mm

Up to 80 mm (3.35”) programmable Z stroke

No vibration, symmetrical mineral casting

No warpage, no thermal drift

CELL SOLUTION

LINE SOLUTION

Integration in any line

Fast, reliable double drive linear motors

No maintenance, longest lifetime

dispense technology.

process control

productivity.

large dispense area.

mineral cast chassis.

linear motors.

MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,

21.5”, 16:9 HD wide touch screen, Windows 10 - 64 bit, ingertip operation, univer-

sal CAD conversion, zoom at camera windows, all-in-one job planning, setup

optimisation, easy deinition of pattern and assistant process support and more

Valves & Pumps

Media Heating Needle and jet heating system

Level Detection Automatic syringe level detection

Full process control meeting automotive standards and more, Adaptation & stabilisation,

Integration & datatransfer of existing pick-and-place machines as Diplan, UniCam,

Cogiscan etc., Vacuum Cleaning Station, High Precision Scale, Heating/Vacuum Tables

Wide range of dispensing applications such as

Solder Paste and SMT Glue, LED Encapsulation,

Silver Epoxy, Dam and Fill, Underill, Cavity Fill,

3D Dispensing via laser height mapping. Standard

cleanroom according to ISO7 (class 10‘000).

Full operator support - Automated error analysis

& KPI. Training, support and troubleshooting via

advanced remote access. Investment protection;

all options and heads retroittable. Modules are

expandable in any direction.

Three processes at the same time. Plug and Play for

valve change. Piezo Jet Valve - super high speed for

low viscosity. Solder Jet Valve, Volume Displace-

ment Valve, Time-Pressure Valve, Archimedean

Screw Valve.

INTEGRATE INTO HIGH SPEED

LINES AND HIGHLY COMPLEX

DISPENSE APPLICATIONS.

tarantula.

Process Max. dispensing speed

(dots/h)

Piezo Jet: 145‘000 Time-Pressure: 26‘000

Pneumatic Jet: 77‘000 Volume-/Screw-: 22‘000

Dispense mode Dot, line, curve, interpolated 3D contour

Accuracy Placement XY dots 40 µm (3σ)

Positioning Z axis 20 µm (3σ)

PCB PCB dimensions 560 x 610 mm (22 x 24“), optional 1’800 x 610 mm (71 x 24“)

Dimensions Machine footprint 1’557 x 1’357 mm (61 x 53“)

Essemtec AG

Mosenstrasse 20

CH-6287 Aesch/LU

Switzerland

FLEXIBLE SMT

SOLUTIONS

CHOOSE YOUR

PREFERENCES

Phone: +41 (0)41 919 60 60

Fax: +41 (0)41 919 60 50

Mail: info@essemtec.com

Wildlife consistently shows us with breathtaking ﬂexibility how nature can

adapt itself to the many dierent demands of its environment; that is what

inspires us! Essemtec AG is a privately owned company with its development

and production site in Switzerland. The product portfolio comprises of produc-

tion equipment for electronic assembly and more. Our high tech solu-

tions can be adjusted quickly and easily to meet wide ranging requirements;

we are therefore able to respond to all manner of customer requests. That’s

why “naturally adaptive” is our motto across all ranges.
