Most Accurate Analyses and
Highest System Versatility
X8011-II PCB
X8068
X8068 SL
Microfocus X-ray Inspection
3D MXI/AXI
X8011-II PCB – Customized 3D MXI X8068 – Extremely Versatile 3D MXI X8068 SL – Very Powerful AXI
Standard-setting, intelligently networked solution for
high-precision offline X-ray inspection
High-performance manual inspection of especially large
and heavy components
Inline handling for special requirements of electro-
mobility and renewable energies
nFull flexibility between manual and semi-automated
inspections
nExtremely accurate magnification of image details
thanks to high-resolution flat-panel detectors
nLarge selection of modules for perfect sample handling
n3D reconstructions with optional computer tomogra
-
phy tools developed by Viscom
nFirst-class automatic analysis routines and other top
features like those of the X8011-II PCB
nIdeal for quality inspection of objects with diameters
of up to 722 mm (28.4")
nVery stable manipulator designed for large and
heavy samples
nDetector pivoting range up to 60°
nSmart AXI solution for inspection objects with special
dimensions and weights
nTransport concept with workpiece carriers for various
object sizes
nCan be seamlessly integrated in final assembly lines
and other production processes
nCustomer-specific system configuration
The area of use of the X8011-II PCB ranges from special
inspection of a single object over sample analysis up to
small series inspections. Even in extremely long continu
-
ous operation, high-quality tube technology guarantees
perfectly stable X-rays. This, together with the use of
state-of-the-art digital flat-panel detectors in the ma
-
chines, ensures optimal image quality even at the highest
magnifications.
With the aid of the optional computer tomography func
-
tions, suspicious areas of the inspection object are located
even more efficiently. Via the extraction of slice images
annoying shadows can be entirely eliminated.
Like the X8011-II PCB, the inspection system X8068 is
equipped with unbeatable features including extremely
easy operation, extensive options for analysis and the
highest resolutions for optimal recognition of details. The
machine makes the most of its special advantages when it
comes to reliable manual X-ray inspection of longer, wider
and heavier objects.
The 60° pivoting range of the detector is identical to that
of the X8011-II PCB and X8068 SL inspection systems from
Viscom and covers a correspondingly large inspection area.
The components examined in the X8068 can weigh up to
15 kg (33 Ibs).
The X8068 SL was developed for the versatile, fully auto
-
mated examination of power electronics components, but
is equally suited for various other inspection tasks and is
particularly recommended when optimal inline X-ray of
solid, heavy and large objects is required. As in the X8068,
special workpiece carriers are used, which can also hold
several smaller test items.
Examples of applications where the inspection system
X8068 SL from Viscom is put to optimal use include, among
others, quality control for battery modules, inverters or
DC/DC converters – and in detail the in-line X-ray inspection
of THT and large-area solder joints.
Brilliant X-ray Results Down to the Finest Detail
Microfocus X-ray Technology by Viscom
Wherever X-ray inspection places the highest demands on
tube performance and image resolution, systems that are
distinguished by very special strengths are required. From
manual inspection (MXI) of individual components to fully
automated inspection and handling (AXI) of large and heavy
objects, Viscom offers the right solution. Brilliant imaging
results are ensured by the use of open microfocus transmis
-
sion tubes that Viscom develops and manufactures in its own
state-of-the-art X-ray compe
tence center. Other tubes are
available on request.
Each of the three machines – X8011-II PCB, X8068 and
X8068 SL – offers customizable configuration options tailored
specifically to individual applications, whether in electronics
manufacturing or in a completely different field.
