3 1 YHP-2(4M) : KGV-M715H-00 MAINTE. PARTS SET No. 1 2 3 4 5 6 7 Qty 4 16 8 20 15 4 4 Part No. 90990-22J009 KV7-M8171-00 KV7-M81D4-00 90440-10J008 90200-02J015 K46-M8527-C0 90990-17J010 Part Name PACKING PLATE,SPLING ROL…
31
YHP-2(4M) : KGV-M715H-00 MAINTE. PARTS SET
No.
1
2
3
4
5
6
7
Qty
4
16
8
20
15
4
4
Part No.
90990-22J009
KV7-M8171-00
KV7-M81D4-00
90440-10J008
90200-02J015
K46-M8527-C0
90990-17J010
Part Name
PACKING
PLATE,SPLING
ROLLER
CIRCLIP
O-RING
FILTER
O-RING
Note
KSYA-3
2
2
3
4
3
4
1
OLD
4
4
5
NOZZLE 61A
ASSY
NOZZLE 62A
ASSY
5
BLACK
GRAY
bit type
non bit type
6
7
