Introducing - The Lizard - Demands for a modern
oven are not only in soldering and curing.
l
3-5 zone relow, up to 400 mm process width
l
Mesh belt or pin chain conveyor
l
Soldering or curing - Full convection heating
for even temperature distribution
l
For solder pastes with or without lead
l
Low thermal stress, eficient heat transfer
l
Temp. metering in heating & cooling zones
l
Integrated microprocessor for proile control
l
Highly reproducible soldering conditions
l
Built-in overheat security switches
CELL SOLUTION
LINE SOLUTION
l
Closed loop controlled conveyor drive system
l
Integrated microprocessor control with LCD
productivity.
combined process
.
lead-free process.
controlled process.
flexible process.
secure process.
MULTITALENT SOFTWARE RO-CONTROL – PC software for simulation, control,
measurement and documentation of perfect solder proiles, job planning, setup
optimisation, easy assistant process support, Integrated microprocessor control
with LCD for easy operation, and more
RO-Control Software Simulation and unlimited storage space for programs
Ecient Cooling Two highly ecient blowers cool down the PCB
Transport Systems Mesh belt or chain conveyor system (with middle support)
SMEMA Integration Link the RO400FC with any other compatible equipment
Process Control Optional flying thermocouples, temperatures can be recorded
Soldering of complex SMD boards requires a well-
controlled process. Demands are not only in
soldering, but also in zone regulation, storing of
proiles and the extra high air circulating volume.
Full operator support - The integrated micropro-
cessor control provides an easy-to-use operator
interface and storage capacity for different solder
proiles. All options and accessories retroittable.
The convection technology applies the same
temperature all over the pcb or substrate, making
programming as easy as possible. Transport width
adjustment of the chain conveyor is motorized.
