WES7 / Win10 - Installation Manual 09/2020 Edition
7
For station software version 7xx:
Operating system USB package WES7(7xx) V3.4, item no. [00117122-xx]
The bootable USB stick contains:
● SIPLACE WinPE for WES7-Restore V2020-1 (to start up the computer)
● SIPLACE WES7 Configurator V2.4.6 (current version for the computer configuration)
● Installation Manual "Operating Systems Windows Embedded Standard 7 / Windows 10 IoT",
item no. [00198622-xx]
● The following image files:
– SIPLACE_WES7x64_iBaseABP402A_V5.wim
– SIPLACE_WES7x64_SIMATICBoxPC827D_V4.wim
– SIPLACE_WES7x64_SIMATICMicroBox427D_V5.wim
– SIPLACE_WES7x86_SIMATICBoxPC627-827B+C_V5.wim
– SIPLACE_WES7x86_iBaseABP402A_V3.wim
For station software version 7xx:
Operating system USB package Win10(7xx) V1.1, item no. [00117132-xx]
The bootable USB stick contains:
● SIPLACE WinPE for Win10-Restore V2019-2 (to start up the computer)
● SIPLACE Win10 Configurator V1.0.4 (current version for the computer configuration)
● Installation Manual "Operating Systems Windows Embedded Standard 7 / Windows 10 IoT",
item no. [00198622-xx]
● The following image file:
– SIPLACE_Win10x64_SIMATICMicroBox427D_V2.wim
– SIPLACE _Win10x64_iBaseABP402A_V2.wim
– SIPLACE_Win10x64_SIMATICBoxPC627C_827C_V1.wim
These and further software packages are also available at the ASM Software Download Center.
WES7 / Win10 - Installation Manual 09/2020 Edition
8
3 Prerequisites for Installation
In Windows, the station computer must be equipped with at least 2 GB memory with WES7, 32-bit
and 4 GB memory with WES7 / Win10, 64-bit respectively. If necessary, station computers in the
field have to be exchanged or upgraded with a memory extension. Please refer to the Technical
Information TI2014-09E04.
3.1 Hardware Components of the Computer System for the
Station / Coplan / BulkFeeder X Computer
Overview Station computer types
X-series
X-series
S
SX-
series
DX-
series
D-series
TX-
series
CA4
CA4 V2
E by
SIPLACE
SIMATIC
BoxPC
627B/827B
WES7
32-bit
WES7
32-bit
WES7
32-bit
WES7
32-bit
SIMATIC
BoxPC
627C/827C
WES7
32-bit
WES7
32-bit
Win10
64-bit
WES7
32-bit
Win10
64-bit
WES7
32-bit
Win10
64-bit
WES7
32-bit
WES7
32-bit
SIMATIC
BoxPC
627D/827D
WES7
32-bit
WES7
32-bit
WES7
64-bit
SIMATIC
MicroBox
427D
WES7
Win10
64-bit
WES7
Win10
64-bit
WES7
Win10
64-bit
iBASE ABP
102-A
WES7
32-bit
iBASE ABP
402-A
WES7
Win10
64-bit
WES7
32-bit
WES7
Win10
64-bit
Table 3-1: Overview Station computer types
WES7 / Win10 - Installation Manual 09/2020 Edition
9
Overview Coplan / BulkFeeder X computer types
Coplan
BulkFeeder X
SIMATIC
BoxPC 627B
WES7
32-bit
SIMATIC
BoxPC 627C
WES7
32-bit
SIMATIC
BoxPC 627D
WES7
32-Bit
SIMATIC
MicroBox 427D
WES7
64-bit
iBASE
ABP 402-A
WES7
32-Bit
Table 3-2: Overview Coplan / BulkFeeder X computer types
Technical data of computers
Name
SIMATIC BoxPC 627B
CPU / clock frequency
Core 2 Duo T7400 / 2.16 GHz
RAM
2 GB
Hard disk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 3-3: SIMATIC BoxPC 627B
Name
SIMATIC BoxPC 827B
CPU / clock frequency
Core 2 Duo T7400 / 2.16 GHz
RAM
2 GB
Hard disk
HDD
Internal DVD drive
Yes
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 3-4: SIMATIC BoxPC 827B
Name
SIMATIC BoxPC 627C
CPU / clock frequency
Intel® Celeron® P4505 / 1,87 GHz
RAM
2 GB
Hard disk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 3-5: SIMATIC BoxPC 627C
