Machine frame
Spare parts
User Manual
© ASYS GmbH
POS Article no. Amount Description SK
1 60.001.417 1 Control panel Berghof AOPT570 2
2 60.002.102 2 Safety switch interlock PSEN ma1.4p-50 2
3 60.002.103 2 Safety switch PSEN ma1.4p-52 2
4 60.008.013 1 Security switch T0-2-1/EA/SVB 2
5 60.008.172 1 Emergency stop button QRUV 2
6 60.012.351 2 Sensor reflection WL100-P4400 2
7 60.027.026 16 Fan 4715-MS-23T-B5-AD00-220V 3
The spare part key (SK) is used to categorize our spare parts: SK = 1 is a wearing part which is not covered
by the warranty. SK = 2 is a component with a limited lifetime. SK = 3 is a component of high reliability.
