Single ball and seat, piston actuated material valve Benefits • Longer lifespan – Wear -resistant seals and har dened components – Unrestricted internal design allows for the free flow of high viscosity materials – Divorce…
Single ball and seat, piston
actuated material valve
Benefits
• Longer lifespan
– Wear-resistant seals and hardened components
– Unrestricted internal design allows for the free flow
of high viscosity materials
– Divorced design separates fluid components from
air components
• Quality dispensing
– No-drip feature creates immediate material shut offf
• Exact consistency
– Short stroke length produces immediate on/off control
of materials being dispensed
Features
• 1/2” NPT ports for higher material flow rates
• Hardened and ground spools
• Unique design allows for easy maintenance
• All stainless steel construction
• Multiple seal configurations are available
396 1-Part No-Drip Series
One-component fluid control valves
Valve data
Dry weight 5.8 lbs. (2.63 kg)
Maximum inlet
fluid pressure
5,000 PSI (344 bar)
Minimum inlet
air pressure
60 PSI (4.2 bar)
Operation
Double air operated; air to open,
air to close
Material delivery Pressure tank, pressure pump
Viscosity range Liquid to paste
Application solutions
• Aircraft and aerospace
• Appliance
• Battery
• Construction
• Electronics and electrical
• Filters
• Lighting and LED
• Solar and wind power
Nordson expertise is always here
when you need it
In highly competitive manufacturing markets, productivity is
vital and performance is essential. That’s why we apply both
to everything we do, whether it’s our products, expertise or
outstanding customer service. We’ll always be there to help
maintain the new standards you’ve set, with expert local
service and support delivered through our teams working
across the globe.
This unique Nordson approach helps you reach new levels
of production, while working more accurately, efficiently and
competitively than ever. Precisely why manufacturers who
demand quality, can rely on Nordson.
Nordson SEALANT EQUIPMENT
Nordson Sealant Equipment
Wixom, MI, USA
Phone: 1.248.412.7920
Email: SealantSales@nordson.com
/company/nordson-industrial-coating-systems
/Nordson_Coating /SealantEquipent
Find out more at:
www.nordson.com/nse
Frequently used models*
+
7440098
Stainless steel and
carbide with polymyte seals
7426154
Stainless steel and carbide
with UHMW-PE seals
7425515
Stainless steel and carbide
with UHMW-PE seals and
heat cartridge capable
* Consult your Nordson representative with
application specifics for accurate valve
capabilities.
+
Many additional models and options are
available.
5.90"
(15.0 cm)
1/4" NPT
air to close
port
1/4" NPT
air to open
port
1/2" NPT
material inlet
port
1/2" NPT
material outlet
port
4.25"
(10.80 cm)
