This Plug & Play Guide corresponds to the following references:
Watch the
product video
Video Guide
Web page of the latest
product version
Information
DMPSD
Complete Rework Station with DT530
This Plug & Play Guide corresponds to the following references:
Ref.
DMPSD-9QB (100 V)
DMPSD-1QB (120 V)
DMPSD-2QB (230 V)
Station
More Information on the
product web page
2
Packing List
The following items are included according to purchased station reference:
DT530
Angled Desoldering Iron .................................................................. 1 unit
Ref. DT530-A
DME
4-Tool Control Unit .................................................................... 1 unit
Ref. DME-9B (100 V)
Ref. DME-1B (120 V)
Ref. DME-2B (230 V)
AM120
Adjustable Micro Tweezers ............................................................. 1 unit
Ref. AM120-A
MSE
Electric Desoldering Module .......................................................... 1 unit
Ref. MSE-B
T245
General Purpose Handle ................................................................. 1 unit
Ref. T245-A
T210
Precision Handle ............................................................................... 1 unit
Ref. T210-A
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - negro plano
200 mm
300 mm
3
ADS
Stand for T210 & T245 Handles ................................................... 2 units
Ref. AD-SF
DTS
Stand for DT530 Angled Desoldering Iron ................................. 1 unit
Ref. DT-SB
AMS
Stand for AM120 Adjustable Micro Tweezers ........................... 1 unit
Ref. AM-SF
SCH
Cartridge Holder ................................................................................ 1 unit
Ref. SCH-A
P405
Pedal ...................................................................................................... 1 unit
Ref. P-405
