Gener al F amil y H7 72HC Pitch [mm/mil] 2.54 / 100 Electrical specific ations Mechanical specifications Connection type (flux-proof) Solder Connection Dimensions T otal length [mm] 30. 00 …
General
Family H772HC
Pitch [mm/mil] 2.54 / 100
Electrical specifications
Mechanical specifications
Connection type (flux-proof) Solder Connection
Dimensions
Total length [mm] 30.00
Press ring diameter [mm] 2.20
Outer diameter [mm] 2.00
Collar height [mm] 0.20
Accessories
High Current Probes
Order code 1007939
