CS1706004J/E-000 YSM40-FL/YSM40R-FL : KLF-M74SH-00 HEAD PARTS SPARE No. Part No. Part Name Q'ty Remarks 1 2 3 4 5 6 KLF-M7156-00 KV7-M8171-00 90115-02J004 90990-28J002 90990-17J081 90990-17J082 FIL TER PLATE,SPRING …
CS1706004J/E-000
YSM40-FL/YSM40R-FL : KLF-M74SH-00 HEAD PARTS SPARE
No. Part No. Part Name
Q'ty
Remarks
1
2
3
4
5
6
KLF-M7156-00
KV7-M8171-00
90115-02J004
90990-28J002
90990-17J081
90990-17J082
FILTER
PLATE,SPRING
BOLT,HEX.SOCKET
WASHER PLAIN
O-RING
O-RING
2
8
4
4
2
2
1
23
2
4
4
3
5
6
NOZZLE
64A/604A AS.
NOZZLE
65A /605A AS.
YAMAHA MOTOR CO,.LTD.
