CONNECTIVE LEAN

STORAGE SOLUTION

Introducing - The Cubus - Traceability down to single component.

The right material, at the right time in the right location.

Storage capacity from 612 to 1540 8mm reels

Two sizes system, unlimited expandability

Reduces logistic problems by 95%

SMD reels of all sizes, trays, boxes & more

Full traceability of all stored items

Software control for MSD components

Lowest ROI of any production system

Conigure – Operate – Integrate!

User reconiguration backed by auto-mapping

Unique intuitive eStorage software

CELL SOLUTION

LINE SOLUTION

Full interface to most production systems and

all major ERP and material management

expandability.

productivity

accuracy.

roi. return on investment

flexibility.

integration.

Language code

Air dry unit

Temperature and humidity cotrol

Individual stack conﬁguration

Extended traceability via eMis

Trays, boxes, spindles and much more

With Cubus, the next generation storage solution,

users can reconﬁgure the internal layout of the

system at any time to adapt to individual, up-to-

date needs. The unique Cubus software, eStorage,

allows users to map and recalibrate the new layout

in less than 20 minutes. The small system footprint

of the Cubus, makes the system one of the most

compact, yet eficient, lexible storage solutions.

The Cubus can be used as total automated SMD

storage solution for small to mid-size companies

as well as automated material replenishment

units for high to super high speed lines. According

to studies over 60% of production line stops

comes from logistics issues; the correct material is

not in the right place when required. Cubus will

reduce this stoppage time by 95%.

The eStorage software for Cubus offers a user-fri-

endly MMI that secures fast, error-free operating

capability. All standard operations, including full

track and trace of consumption and inventory

levels, are only few clicks away. MSD control is also

included. eStorage guarantees the right material,

at the right time in the right location.

eStorage, with the strategical partner Cogiscan, the product CO-Nect and the

eStorage standard interface, process integration is easy. Over a world wide recog-

nized middleware backbone system Cubus can be integrated into all Essemtec

pick-and-place and dispensing solutions as well as any other production equip-

ment from 3rd party venders. Connection to ERP, SAP, main stock or custom

solutions are also possible.

optional.

cubus. regular cubus. large

Maximum capacity 4-7” reels: 612 (8 mm tape only)

or any mix of 4-15” reels

With spindle up to 1’022 reels (8 mm tape)

4-7” reels: 932 (8 mm tape only)

or any mix of 4-15” reels

With spindle up to 1’540 reels (8 mm tape)

Storage SMD Reels of all sizes, trays, boxes, bulk components and small sticks

Access time 5-6 reels per minute

Reel detection Automatic diameter and width detection, automatic barcode detection

Database Data access via Access table; Connection to existing SQL systems

optional or on request

CHOOSE YOUR

PREFERENCES

Wildlife consistently shows us with breathtaking ﬂexibility how nature can

adapt itself to the many dierent demands of its environment; that is what

inspires us! Essemtec AG is a privately owned company with its development

and production site in Switzerland. The product portfolio comprises of pro-

duction equipment for electronic assembly and more. Our high tech solu-

tions can be adjusted quickly and easily to meet wide ranging requirements;

we are therefore able to respond to all manner of customer requests. That’s

why “naturally adaptive” is our motto across all ranges.
