MDOC
-
SOFT50125
1
Explanation Document of changed Printer
History file format
YSP
SMT Software Engineering Group
1. Conveyor History file (YvpConveyorLog.csv)
2. Squeegee History file (YvpSqueegeeLog.csv)
3. Mask History file (YvpMaskLog.csv)
4. Cleaner History file (YvpCleanerLog.csv)
Format of the following history files of YSP has been upgraded.
Go to the next page for details.
MDOC
-
SOFT50125
2
１．Conveyor History file(YvpConveyorLog.csv)
• Version of the format is changed from [1.00] to [1.10].
• [Lane] is added to the item.
V1.00 MultiLanguage
EN Item Date Counter … Error Counter Error percentage(%)
EN Main Stopper 1900/1/1 12:00 0 0 0
EN Exit Stopper 1900/1/1 12:00 0 0 0
V1.10 MultiLanguage
EN Item Date Counter … Error Counter Error percentage(%) Lane
EN Main Stopper 1900/1/1 12:00 0 0 0 1
EN Exit Stopper 1900/1/1 12:00 0 0 0 1
MDOC
-
SOFT50125
3
２．Squeegee History file(YvpSqueegeeLog.csv)
• Version of the format is changed from [3.00] to [3.10].
• [Table] is added to the item.
V3.00 MultiLanguage
EN Squeegee Type Item Squeegee Direction … Error Counter Error percentage(%)
EN Double Squeegee Urethane 250mm 0 0 0
EN Double Squeegee Urethane 300mm 0 0 0
V3.10 MultiLanguage
EN Squeegee Type Item Squeegee Direction … Error Counter Error percentage(%) Table
EN Double Squeegee Urethane 250mm 0 0 0 0
EN Double Squeegee Urethane 300mm 0 0 0 0
