InJet ® 3179 CRD TECHNICAL DATA SHEET www.dct.cleaning 1 process chamber, fully automatic solution PLC + 8,4" touchscreen Controlled STS arms - 6 arms Lockable travelling wheels 100% closed circuit Cleaning uid hea…

100%1 / 6
Application name Recommended
application
Recommended
temperature
Recommended
time
Capacity
per shift
Stencils
20 – 40°C 20 min. 48*
Misprints 20 – 40°C 20 min. 1680 **
3 INDIVIDUAL PROCESSES
CLEANING PARAMETERS
highly recommended
stencil (736x736 mm) per 8 hours (work shift)
eurocards (100x160 mm) per 8 hours (work shift)
*
**
www.dct.cleaning
C
R
D
InJet
®
3179 CRD TECHNICAL DATA SHEET
C
CLEANING
RINSING
DRYING
R
D
InJet
®
3179 CRD
TECHNICAL DATA SHEET
www.dct.cleaning
1 process chamber, fully automatic solution
PLC + 8,4" touchscreen
Controlled STS arms - 6 arms
Lockable travelling wheels
100% closed circuit
Cleaning uid heating
Rinsing uid heating
hot air drying
Emergency stop button
Chimney ap with draft diverter
Pneumatic door lock
4 powerful hot air blowers
Electronic monitoring of the uid pressure
High capacity stainless steel lter housing - DCT utility design
100% stainless steel design - 15 years warranty:
- cleaning, rinsing and drying distribution
- process chamber
- storage tanks
Designed for easy maintenance and servicing
Optimized stainless steel nozzles
Spare parts (base kit)
STANDARD EQUIPMENT
Fluid leakage tray - stainless steel
Status light
Acoustic signalization
Barcode reader, including software
Traceability oine (CD view SW)
OPTIONAL ACCESSORY - MANUFACTURING PART OF THE MACHINE
continued on next page
www.dct.cleaning
InJet
®
3179 CRD
TECHNICAL DATA SHEET
Mechanical carrier frame for PCBs
Spare adjustable arm for mechanical carrier frame for PCBs
Mechanical table holder for PCBs or stencils
External pump for comfortable uid relling
External pump manipulation trolley – position for pump and 2 x 25 liter can
100 l tank for pre-rinsing - closed circuit without ltration
25 l external ltration set 3 x 25 lit (1 x active carbon, 2 x Ionex, 1 x mech. lter) - SANDWICH ltration
OPTIONAL ACCESSORY - NOT MANUFACTURING PART OF THE MACHINE
Mechanical carrier frame for squeegees DEK
Mechanical carrier frame for VectorGuard stencils
Mechanical carrier frame for frameless stencils
Mechanical carrier frame for small stencils (15,17 and 23 inch)
Mechanical carrier frame according customer specication
OPC server setting - IT specialist service
Automatic uid relling
Automatic uid discharging
other customized modications
OPTIONAL ACCESSORY - INDIVIDUAL ORDER
Traceability online OPC server
SW for CVA calculation (installed on android platform or cleaning device)
RR kit - complete machine preparation for pre-rinse
Conductivity measurement - pre-rinse circuit
Conductivity measurement - rinse circuit
