INTELLIGENT TAPE FEEDERS FOR
FLEXIBLE PRODUCTION ENVIRONMENTS
SIPLACE X feeder modules stand
out because three characteristic
properties: they are robust,
intelligent and set-up friendly.
Particularly in high-mix
production environments where
frequent set-up changes can have
a major effect on profitability, the
SIPLACE X feeder modules
present an ideal solution.
Because of their unique design, all SIPLACE
X-feeders can be set up quickly and easily on the
component cart. When the placement program is
downloaded, the software automatically configures
the tape pitch, feeder speed and other functions.
For you, this means faster and more reliable setups
and more job lots per shift.
SIPLACE X-feeders are available as 8mm
SIPLACE X dual-track feeders and single-track
feeders. The optimized price-performance ratio of
the SIPLACE 2x8mm dual-track feeder lets you
reduce your equipment investment considerably.
The flexible 8mm SIPLACE X-feeder, on the other
hand, is ideal for the floating setup concept with
SIPLACE LES.
SIPLACE Feeder
SIPLACE X Feeder
The information in this specification consists only of general descriptions and / or performance features, which is not contractually binding.
Any specific performance features / capabilities will only be binding if contractually agreed. Subject to changes without notice.
A10011-ASM-G53-EN Edition 4-04/2011
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Str. 44
81379 Munich, Germany
Tel: +49 89 20800-27819
Fax: +49 89 20800-36692
smt-solutions.de@asmpt.com
www.asm-smt.com
SIPLACE X Feeder
Other outstanding features of the intelligent
SIPLACE X feeder modules are:
Robustness
A contact-less power supply and robust motors
provide the SIPLACE X-feeders with a long
useful life. In addition, the feeder’s drive system
ensures a high level of reliability when it comes
to feeding components.
Dynamic fill level process
When a component is about to run out, the
feeder’s LED changes from green to orange a.
This gives the operator sufficient time to splice
on a new tape.
High feeding precision
The SIPLACE X-series feeder features an
exceptionally fast but nevertheless highly precise
supply of components, which particularly comes
TECHNICAL DATA
Feeder type
8 mm X
2x8mm X
12 mm X
16 mm X
24 mm X
32 mm X
44 mm X
56 mm X
72 mm X
88 mm X
Location
1
2
2
3
3
4
5
6
7
9
Transport increment (mm)
1/2/4/8
1/2/4/8
4 – 16
4 – 20
4 – 32
4 – 40
4 – 52
4 – 64
4 – 80
4 – 96
Max. tape heigt (mm)
3,5
3,5
6,5
25
25
25
25
25
25
25
into play with the innovative 20-Nozzle
Collect&Place Head. Thanks to this high level of
accuracy, even components like 01005s can
beprocessed.
Intelligence
Each feeder has a unique ID number. When the
operator scans in a component barcode, the
program assigns it to the appropriate feeder. This
provides an important foundation for the set-up
verification and the component traceability
required by many manufacturers today.
With all these features, SIPLACE X feeders provide
exceptional performance while still being very easy
to handle. By setting milestones with respect to
built-in intelligence, automation and feed rate they
enable maximum performance, accuracy and
robustness.
Tape reels 178 to 483 mm in diameter (7˝ - 19˝)
Changeover time ≤ 8 s
