Success Story – Semiconductor
Application Story
Type of Customer
Our customer is a major international semiconductor
manufacturer.
Our Customer’s Requirements
Our customer wanted an inspection system for DRAM, SDRAM,
and SSD memory cards. These products included small 0201
metric components that could not be manually inspected.
As the company intended to achieve mass production volumes,
speed with quality assurance was vital. It was also important to
reduce operator costs to ensure competitiveness.
Our Solution –
The Nordson SQ3000™ AOI System
Our customer needed a 3D automated solution that would
capture defects earlier in the manufacturing process. Factory
automation combined with a robust and reliable sensor
solution would ensure fast inspection while providing accurate
data. It would also need to accommodate variation in the
evolution of the product, and inspect gold ngers, and detect
non wet ux, missing parts, and correct component alignment.
The SQ3000 has the lowest escape rate on the market. By
optimizing inspection algorithms, line cycle times could be
accelerated. Increased eiciency and automation would reduce
the need for operator intervention, while the easy user interface
would reduce programming and training times, further
reducing times.
The SQ3000’s Multiple Reection Suppression (MRS) sensor
technology would mitigate reections that can lead to
measurement inaccuracies and false reading caused by small
and shiny components. The system would be reliable, stable,
and have low mean time between failures.
www.nordson.com/TestInspect | +1 760.918.8471
Copyright © Nordson Corporation. All rights reserved.
For more information,
speak with your Nordson
representative or contact
your Nordson regional oice
Nordson Test & Inspection
Europe, SEA, Africa
ti-sales-eu@nordson.com
Nordson Test & Inspection
Americas
ti-sales-us@nordson.com
Nordson Test & Inspection
China
ti-sales-cn@nordson.com
Nordson Test & Inspection
Japan
ti-sales-jp@nordson.com
Nordson Test & Inspection
Singapore
ti-sales-eu@nordson.com
Nordson Test & Inspection
Taiwan
ti-sales-tw@nordson.com
Nordson Test & Inspection
Korea
ti-sales-korea@nordson.com
Success Story – Semiconductor Application Story
The Result
All customer objectives were met. Escape rates were lowered, operator costs reduced, and quality
assurance levels increased. Defects were qualied, and traceability facilitated. The company’s
customer valued the overall commitment to the highest quality standards.
For more information on Nordson Test and Inspection products, services, or solutions,
visit our website at www.nordson.com/TestInspect
Solder Ball Flip Lied
Vendor Related Surface Defects Insuicient Contamination Metallic Bridge
GF Defects
