EXP ANSION IN ANY DIRE C TION. VERS A TILE FROM PRO T O T YPING T O HIGH SPEED PRODUC TION. MUL TIT ALENT SOFTW ARE A T YOUR FINGERTIPS State of the art , full graphics, 21. 5” , 16 : 9 HD wide touch scr een, Windows 10 …
RELENTLESS PLACING
AND DISPENSING
Introducing – The Puma – State of the art
technology. Expandable in any direction.
l
Highspeed Placement and Jet-Dispensing
l
2 or 4 placement-axes and 1-2 dispense processes
l
Optimum 18’100 cph, up to 54’300 cph inline
l
Optimum 145’000 dots/h (with Piezo Jet Valve)
l
Up to 280 Feeder on 2 m
2
(up to 420 inline)
l
PCB size 560 x 610 mm, optional 1’800 x 610 mm
l
No vibration, symmetrical mineral casting
l
No warpage, no thermal drift
l
Nonstop production, Smart electronic feeder
l
Nonstop feeder and production changeover
CELL SOLUTION
LINE SOLUTION
l
Fast, reliable double drive linear motors
l
No maintenance, longest lifetime
combined process.
productivity
.
small footprint.
mineral cast chassis.
quick changeover.
linear motors.
EXPANSION IN ANY DIRECTION.
VERSATILE FROM PROTOTYPING
TO HIGH SPEED PRODUCTION.
MULTITALENT SOFTWARE AT YOUR FINGERTIPS State of the art, full graphics,
21.5”, 16:9 HD wide touch screen, Windows 10 – 64 bit, ingertip operation,
universal CAD conversion, zoom at camera windows, all-in-one job planning,
setup optimisation, stock management, ERP/MES connection, data analysis, line
management and more.
Laser Height Measurement Compensation of PCB warpage
Dispensing and Jetting Vacuum cleaning station for nozzles and tips
Tray Slider Unique system to increase the amount of trays
Increase Boardsize Table extension to increase the processable board size
Additional: Electrical component test system, vision box to increase component size
to be placed, reel-to-reel, bulk components and more
Conigurable heads with 1-4 placement-axis.
2,5D and 3D dispensing and jetting, High resolution
digital Cognex vision system with auto component
teach-in and irregular ball recognition.
Full operator support - Automated error analysis
& KPI. Training, support and troubleshooting via
advanced remote access. Investment protection;
all options and heads retroittable. Machine
expansion in any direction.
Multi lexible feeder, multi lane cassette or highly
accurate single lane feeder. Tape, Stick, Strip,
Palettes and Tray slider. Largest component
spectrum; 01005 up to 80 x 80 mm, component
height up to 25 mm.
optional.
puma.
puma.
2
puma.
4
Productivity Optimum placement speed 6’700 cph (1-axis) 11’200 cph (2-axes) 18’100 BE/h (4-axes)
Optimum jetting speed up to 145’000 dots/h
Feeder Feeder capacity 8 mm tape 260 (140 inline) 260 (140 inline) 280 (160 inline)
Components Component size range 01005 - 33 x 80 mm, optional 80 x 80 mm
Accuracy Placement accuracy (x, y) 50 µm @ 3σ
PCB Max. PCB dimensions 560 x 610 mm (22 x 24“), optional 1’800 x 610 mm (71 x 24“)
Dimensions Machine footprint 1’557 x 1’357 mm (61 x 53“)
Essemtec AG
Mosenstrasse 20
CH-6287 Aesch/LU
Switzerland
FLEXIBLE SMT
SOLUTIONS
CHOOSE YOUR
PREFERENCES
Phone: +41 (0)41 919 60 60
Fax: +41 (0)41 919 60 50
Mail: info@essemtec.com
Wildlife consistently shows us with breathtaking flexibility how nature can
adapt itself to the many dierent demands of its environment; that is what
inspires us! Essemtec AG is a privately owned company with its development
and production site in Switzerland. The product portfolio comprises of produc-
tion equipment for electronic assembly and more. Our high tech solutions
can be adjusted quickly and easily to meet wide ranging requirements;
we are therefore able to respond to all manner of customer requests. That’s
why “naturally adaptive” is our motto across all ranges.
Disclaimer & Copyright:
The information contained in this brochure is for general information purposes
only. For more information see the specification sheet. All materials contained
in this brochure are copyright © Essemtec AG, Switzerland, November 2017
4 Placement + 1 Dispensing
2 Placement + 2 Dispensing
4 Placement
