NA101/NA102 NANE Updating Kit C11 5/ NASE Updating Kit C115 INSTRUCTION MANUAL

100%1 / 12
NA101/NA102
NANE Updating Kit C115/
NASE Updating Kit C115
INSTRUCTION MANUAL
Adjustable Nano Tweezers .................... 1 unit
Ref. AN115 -A
Splashguard .................................... 2 units
Nano Handle ............................................ 2 units
Ref. NT115 -A
Soft Foam Grip
(Ref. see page 5)
Manual .................................................. 1 unit
Ref. 0029833
Packing List
The following items are included in
Ref. 0021101:
This manual corresponds to the following references:
0021101 - NA101 0021102 - NA102
NANE Updating Kit C115 NASE Updating Kit C115
The following items are included in
Ref. 0021102:
The following items are included for Ref. 0021101 and Ref. 0021102:
Nano Handle ............................................... 1 unit
Ref. NT115 -A
Soft Foam Grip
(Ref. see page 5)
2
AN115
Adjustable
Nano Tweezers
NAE
2-Tool
Nano Control Unit*
Connections with Handle and Tweezers
Power Socket
Main Switch
C115
Cartridges*
*not included, sold separately
NT115
Nano Handle
C115
Cartridges*
NAE
2-Tool
Nano Control Unit*
Connections with 2 Handles
Power Socket
Main Switch
NT115
Nano Handle
NT115
Nano Handle
Note:
To use NT115-A, AN115-A and C115 cartridges with NAE-A and NAE-B the control unit software
must be updated to a software version number higher than 8886229. See the software updater
available at www.jbctools.com/software.html
C115
Cartridges*
C115
Cartridges*
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
