Technical specifications
Maximum output per hour 70 k 35 k 9k
(51k IPC 9850) (24.3k IPC 9850) (7.5k IPC 9850)
Placement quality < 1 dpm < 1 dpm < 1 dpm
Placement accuracy @ CpK1 35 mm for passives 35 mm for passives 35 mm for passives
25 mm for QFP/BGA/FC 20 mm for QFP/BGA/FC
Minimum component size (LxW): 0.4 x 0.2 mm (01005) 0.4 x 0.2 mm (01005) 0.6 x 0.3 mm (0201)
Maximum component size (LxW): 17.5 x 17.5 mm (0.69x0.69”) 45 x 45 mm (1.77x1.77”) 120 x 52 mm (4.72x2.05”)
Maximum component height (LxW)
Standard: 15 mm (0.60”) 15 mm (0.60”) 25 mm (0.98”)
Optional: 21 mm (0.83”) 50 mm (1.97”)
Programmable placement force 1.5 to 8 N 1.5 to 8 N 4 N
Optional: 80N
(lower forces on request)
Maximum board size: (LxW)
Single lane: 555 x 558 mm 555 x 558 mm 555 x 558 mm
(21.8 x 22”) (21.8 x 21.9”) (21.8 x 21.9”)
Dual lane: 555 x 254 mm 555 x 254 mm 555 x 254 mm
(21.8 x 10”) (21.8 x 10”) (21.8 x 10”)
Dual lane in single lane mode: 555 x 460 mm 555 x 460 mm 555 x 460 mm
(21.8 x 18”) (21.8 x 18”) (21.8 x 18”)
Optional board length (Dual/Single Lane) 845 mm (33”) 845 mm (33”) 845 mm (33”)
Minimum board size: 50 x 50 mm (2 x 2”) 50 x 50 mm (2 x 2”) 50 x 50 mm (2 x 2”)
Board thickness: 0.3 to 6 mm 0.3 to 6 mm 0.3 to 6 mm
Automatic toolbit exchange Nozzles Nozzles, grippers Nozzles, grippers
Maximum tape feeding positions (8 mm): 124 SF feeders 124 SF Feeders 129 SF Feeders
Feeding options Tape, stick, tray, tubes Tape, stick, tray, tubes Tape, stick, tray, tubes
(other feeder types on request)
Footprint excl. feeders (LxW) 1,170 x 1,844 mm 1,170 x 1,844 mm 1,170 x 1,844 mm
(46.06 x 72.60”) (46.06 x 72.60”) (46.06 x 72.60”)
