T600 Series UV-Vis Spectrophotometer
Our purpose:
To carry out the analysis and test efficiently, conveniently, accurately and reliably
INSTRUMENT CHARACTERISTICS
01 Convenient Operation, Free Extensibility
• Thanks to the scientific and reasonable process design, you can
start your measurement work by three clicks.
• The instrument system platform can be extended for applications to
achieve online teaching, intelligent assessment, water quality test
and other functions.
• Customizable user specific methods that support storage device and
network form migration.
• Data can be exported to a USB flash disk, and storage space
supports extensibility.
Model Selection Table
Model
Quasi-double
light beams
Double
light
beams
5-grade
changeable
slit
Fixed
slit
Color
touch
screen
T600AS
√
√
√
T600A
√
√
√
T600S
√
√
T600B
√
√
02 Stable Performance, Fast and Correct
• Completes a spectral scan in 2 seconds, with a spectral scanning
speed of 30000 nm/min.
• - 4 to+4 Abs absorbance range, no fear of high concentration
samples.
• Easy to cope with the test of complicated samples with the
minimum spectral bandwidth of 0.2 nm.
• The instrument indicators have passed the testing by the
authoritative institute of metrology, with an accuracy of Level I.
• Network port communication, stable and fast.
03 Beautiful Design, Practical
• Excellent finish with firm and smooth lines.
• 9.7-inch capacitive touch screen.
• The paint surface is resistant to corrosion by acids, alkalis and
organic solvents.
• Anti-tipping and liquid leakage of the sample cell.
Performance indicator
Maximum allowable error of wavelength
±0.1nm（ D2@656.1nm ）
± 0.3 nm full wavelength range
Wavelength repeatability
≤0.1nm
Wavelength transmission speed
Max. wavelength scanning speed 30000 nm/min
Spectral bandwidth
T600S, T600AS, T700S, T700AS: 0.2, 0.5, 1.0, 2.0, 5.0 nm
Stray light
＜ 0.01T% (220nm); ≤ 0.05T%（360nm）
Photometric range
-4.0-4.0Abs
Maximum allowable error of transmittance
±0.3%T（0-100%T）
±0.002Abs(0.5Abs)
±0.004Abs（1.0Abs）
Transmittance repeatability
＜0.1%T（0-100）%T
＜0.0002Abs(0.5Abs)
＜0.0002Abs(1Abs)
Noise
≤0.05%T RMS: within 0.00005Abs (700nm)
Baseline flatness
±0.0005Abs
Drift
≤ 0.1% T (500nm, preheating for 1h, test for 1h) ±0.0004Abs/h（500nm）
Photometric linearity
≤1% across the measurement range
Beijing Purkinje General Instrument Co., Ltd.
Address
No. 3, Pingsan Road,
Pinggu District, Beijing
Website:
http://www.pgeneral.com.cn
Sales hotline
010-69910666
Switchboard
+86-10-69910000
Email:
info@pgeneral.com.cn
Functional Indicators
Optical system
T600 series quasi-double light beams
Screen
T600A, T600AS, 9.7 inch color capacitive touch screen;
T600B, T600S,: no screen;
Light source
Imported tungsten halogen lamp, imported deuterium lamp
Detector
Imported silicon photodiode
Optical grating
Imported blazed holographic grating
Data export
Data can be exported to a USB flash disk
Printing
Supports all printer models
Online mode
Network port communication, supports wifi
Overall dimensions
Dimensions of T600A and T600AS spectrophotometers: width 512.1, height 274, depth 505
Dimensions of T600B and T600S spectrophotometers: width 512.1, height 249.7, depth 505
Outer package size: width 715, height 575, depth 715
Note: Unit: mm
Weight
Bare instrument: 28 kg
Wavelength range
190-1100 nm
Power
150W
Optional Accessories
Optional accessory
Functional description
Standard optical path sample cell
A 10mm * 10mm conventional cuvette can be selected for use
You can also choose to use a micro cuvette with an optical path of 10mm to reduce the volume of
the measurement sample used
Adjustable optical path fixed length sample
cell
Colorimetric cells with optical paths of 5, 10, 20, 30, 40, 50 and 100 mm can be accommodated
through insertion
Adjustable optical path quintuplet long sample
cell
Colorimetric cells with optical paths of 5, 10, 20, 30, 40, 50 and 100 mm can be accommodated
through insertion
The sample cell can be freely switched from No. 1 to No. 5 for convenient measurement
Octuple cell
Optional 10mm * 10mm conventional cuvette for use
The sample cell can be freely switched from No. 1 to No. 8 for convenient measurement
Solid sample cell frame
Changeable angle sample table
Relative mirror reflection
Adjustable optical path quintuplet
long sample cell
Adjustable optical path fixed
length sample cell
Test tube rack
Octuple cell
Micro sample cell
Double-channel peristaltic pump
accessory
Thermostatic sample cell
Quintuplet thermostatic cell
Automatic sampler
Note: The T600 series is taken as an example, and the T700 series is also provided with accessories with the same functions
