General
Family H100
Pitch [mm/mil] 2.54 / 100
Mechanical specifications
Connection type (flux-proof) Wire Wrap
Dimensions
Total length [mm] 35.00
Press ring diameter [mm] 1.81
Outer diameter [mm] 1.68
Basic Contact Probes
Order code 1157475
Family drawing
All measurements are in mm.
