Convenient surface temperature Better than any standard*: Thanks to the patented MEMMER T air circulation system, the surfaces and operating elements of the new appliances only heat up moder ately, even at a chamber temp…

GreenLAB

WORTH KNOWING

No other manufacturer has more

experience in Peltier technology and

offers a greater variety of these pre-

cise and energy-efficient temperature

control appliances than Memmert.

The triumph of Peltier technology

At the turn of the millennium, Memmert opened a new chapter

in its history of innovation. The heating and cooling process of

the interior in temperature control appliances is by nature very

energy intensive. Therefore, Memmert was the first manufacturer

that consequently developed energy-efficient and environmentally

friendly laboratory appliances.

Saving resources – a task for the future

At Memmert, every innovation is thoroughly tested with respect to its sustainability. Whether climate chambers

or conventional heating and drying ovens, all appliances feature outstanding energy efficiency, thanks to their

finely tuned control technology in connection with sophisticated individual heating concepts.

The insulation concept has been optimised. Insulation of up to 90 mm and insulation inserts in the door are two

important changes to almost completely prevent thermal bridges and thus heat emission from the chamber.

WORTH KNOWING

All Memmert appliances are made

of stainless steel and thus nearly

100 % recyclable.

0 watt

Memmert heating

ovens 108 litres

Competitor 1 Competitor 2 Competitor 3

200 watt

400 watt

600 watt

800 watt

1000 watt

1200 watt

542

959

934

849

Heat emission at 250 °C, air ﬂap closed

In the same way as in a heat pump, in heating

operation, thermal energy is removed from the

ambient air and introduced into the chamber.

Due to the closed Peltier cooling system, no

outside air is exchanged. The advantages:

No dehumidification of the chamber and

heavily reduced risk of contamination.

In contrast to compressor technology, Peltier

technology works in a particularly economical

and energy-saving manner at temperatures close

to the ambient temperature, since energy is only

required if heating or cooling is needed. Heating

and cooling are perfectly fine-tuned.

80 W cooling

150 W electrical power

230 W heat dissipation

Peltier element

Cooling operation

150 W electrical power

80 W ambient heat

230 W heating

Heating operation

Peltier element

Convenient surface temperature

Better than any standard*: Thanks to the patented MEMMERT air circulation system,

the surfaces and operating elements of the new appliances only heat up moderately,

even at a chamber temperature of 300 °C

e. g. EN 61010-1, EN 61010-2-010

International power connection

High-temperature connectors on the rear of the appliance for single-phase power

connection according to country specific systems and IEC standards

USB port on a TwinDISPLAY model

• Standard for all TwinDISPLAY appliances

• Uploading programmes and reading out logs

• Protecting appliances with individual user-ID function, and much more…

Easy transport

• Recessed grips for safe carrying

• Easy handling in the laboratory

Opening the door as if by magic

• With the feet or elbows: Almost vibration-free opening and closing of the door,

even if the hands are not free

• Unproblematic change of the door hinge to the left side also after commissioning

Convenience

Multi-point calibration

For all appliances, free-selectable calibration points for temperature, humidity, pressure,

, etc. can be set directly via the ControlCOCKPIT.

Drag, drop & go!

User-friendliness and simple operation is the key factor of all models with SingleDISPLAY and TwinDISPLAY.

Naturally, the same applies to the control and logging software AtmoCONTROL. Simply drag & drop the

graphical symbol for the required parameter in the programming field and let’s go!

AtmoCONTROL for all appliances

Thanks to the AtmoCONTROL software,

the data logger of all Memmert appliances

can be read out and saved as different file

formats.

All TwinDISPLAY appliances are supplied

with the AtmoCONTROL software on a USB

stick and offer a multitude of possibilities

for programming and documentation.

Safety

Fan speed

Certain standard applications require controlled fan function and

fixed air exchange rates. Therefore, all TwinDISPLAY appliances

can optionally be equipped with a fan speed monitoring system.

AtmoCONTROL

software

Automatic alarm

With the AtmoCONTROL software, alarm notifications can be sent out to an e-mail address. The optional

MobileALERT makes it possible to send the alarm notifications by SMS to a mobile phone.

Memmert is concerned about your safety as well as the safety of your chamber load. Therefore, all Memmert

temperature control chambers feature an electronic temperature monitoring system, a mechanical temperature

limiter acc. to DIN 12880 and an integrated auto-diagnostic system with optical and acoustic alarm as a

standard.

Even more safety in TwinDISPLAY models

TwinDISPLAY appliances are equipped with an overtemperature monitor as well as two high-grade Platinum

temperature sensors Pt100 for mutual monitoring and operation transfer at same working temperature in

case of an error. Particularly in ramp operation, the integrated temperature monitoring system AutoSAFETY

can be activated to automatically follow the set temperature with a freely selectable tolerance. Individual

MIN-/MAX-values can be set for over/undertemperature as well as for all other parameters like relative

humidity, CO

, O

and pressure (vacuum).
